NI PXIe-1071 PXI Express Chassis

Product Type: PXI Express Chassis
Model: PXIe-1071
Part Number: 781368-01
Manufacturer: National Instruments (NI)

Technical Specifications

Parameter	Specification
Chassis Type	PXI Express
Total Slots	4
Peripheral Slots	3
Hybrid Slots	3
System Bandwidth	Up to 3 GB/s
Per-Slot Bandwidth	Up to 1 GB/s
PCI Express Link	Gen 1 ×4
Power Supply	AC
Total Power	230 W
Slot Cooling	38 W per slot
Reference Clocks	10 MHz / 100 MHz
Dimensions	177 × 257 × 214.2 mm
Weight	Approx. 5.94 kg
Cooling	Forced-air cooling
Form Factor	Compact desktop / rack-mount

The PXIe-1071 has one system-controller slot and three peripheral slots. Its hybrid slots support PXI Express and compatible PXI modules, providing flexible configuration for modular test systems.

Advantages & Features

Compact 4-Slot Design: Ideal for desktop, portable, and space-constrained test systems.
High-Speed Backplane: Provides up to 3 GB/s total system bandwidth.
Flexible Module Compatibility: Supports PXI Express and compatible PXI hybrid modules.
Reliable Cooling: Provides approximately 38 W of cooling capacity per slot.
Precision Timing: Includes 10 MHz and 100 MHz reference clocks for synchronized measurements.
Modular Architecture: Allows users to combine DAQ, digital I/O, RF, signal-generation, and measurement modules in one system.
Industrial Reliability: Designed for demanding automated test and measurement applications.

Typical Applications

Automated Test Equipment (ATE)
Electronic device testing
Semiconductor testing
Data acquisition and signal measurement
Functional and validation testing
RF and wireless testing
Aerospace and defense testing
Automotive electronics testing
Production-line testing and quality control

NI PXI Express platforms are particularly suited to high-channel-count and high-speed automated measurement systems.

Important Notes

Confirm that the installed PXI/PXIe modules are compatible with the PXIe-1071.
Do not exceed the chassis power and cooling capacity.
Ensure adequate airflow around the chassis during operation.
Install filler panels in unused slots to maintain proper airflow.
Use the correct AC power cable for the destination country.
Follow ESD precautions when installing or removing PXI modules.
For rack installation, use the appropriate NI rack-mount accessories.
Check the required controller/interface before building the complete PXI system.
