Murrelektronik 7000-12411-2340500 Industrial Connector

Product Type: M12 Sensor/Actuator Cable Assembly
Model: 7000-12411-2340500
Manufacturer: Murrelektronik
Connection: M12 Female, 90°
Cable Length: 5 m

The Murrelektronik 7000-12411-2340500 is a 4-pin M12 A-coded female sensor/actuator cable assembly with a 90° connector, integrated 2× LED (PNP) indicators and a 5 m PUR cable. It is designed for industrial sensor and actuator connections.

Technical Specifications

Parameter	Specification
Model	7000-12411-2340500
Connector	M12 Female, 90°
Number of Pins	4
Coding	A-coded
Cable Length	5 m
Cable	PUR 4 × 0.34 mm²
Cable Color	Gray
Cable End	Open / Flying Leads
LED	2 × LED, PNP
Operating Voltage	24 V DC
Voltage Range	18–30 V DC
Rated Current	4 A per contact
Cable Max. Voltage	300 V
Protection Rating	IP65 / IP66K / IP67
Connector Thread	M12 × 1
Tightening Torque	0.6 Nm
Contact Material	Copper Alloy
Contact Plating	Gold
Operating Temperature	-30 to +85°C*
Cable Conductor	Stranded Copper
Cable Jacket	PUR
Cable OD	Approx. 4.5 mm
Country of Origin	China**
EAN	4048879203562

*Actual cable temperature range depends on the cable application.
**Murrelektronik's current product page lists CN as the country of origin for this specific item.

Advantages & Features

4-Pin M12 A-Coded Design — Compatible with common industrial sensors and actuators.
Integrated LED Indicators — Two PNP LEDs provide convenient visual status indication.
90° Connector Design — Helps reduce cable bending and save installation space.
5 m PUR Cable — Flexible and suitable for demanding industrial environments.
Gold-Plated Contacts — Provides reliable electrical conductivity and corrosion resistance.
IP65/IP66K/IP67 Protection — Suitable for environments exposed to dust, moisture and water.
Oil & Coolant Resistant — PUR cable is suitable for typical machine-building environments.
Drag-Chain Suitable — Cable is designed for dynamic applications and can withstand up to 10 million bending cycles under specified conditions.
