IFM IM5115 Inductive Proximity Sensor

Product Type: Inductive Proximity Sensor
Model: IM5115
Manufacturer: ifm electronic
Electrical Design: PNP, Normally Open (N.O.)
Sensing Range: 20 mm
Connection: M12 connector

The IFM IM5115 is a rectangular inductive proximity sensor designed for non-contact detection of metal objects. It uses a PNP normally-open output, offers a 20 mm flush sensing range, and is suitable for industrial automation and position-detection applications.

Technical Specifications

IFM's current technical documentation confirms the 10–36 V DC supply, PNP N.O. output, 20 mm sensing range, 200 mA output capability and 40 × 40 × 54 mm housing.

Advantages & Features

• 20 mm Sensing Range — Provides reliable detection of metal targets without physical contact.
• PNP Normally-Open Output — Easily integrates with common PLC digital inputs.
• Flush Mounting — Allows convenient installation while protecting the sensing face.
• IP67 Protection — Suitable for dusty, wet and demanding industrial environments.
• M12 Connection — Provides a standardized and easy-to-maintain industrial connection.
• Compact Rectangular Housing — Suitable for machine and conveyor installations.
• LED Status Indication — Makes sensor operation easy to monitor.
• Reverse Polarity Protection — Helps protect the sensor against wiring errors.
• Gold-Plated Contacts — Supports reliable long-term electrical connection.

Typical Applications

• Industrial automation
• Machine position detection
• Conveyor systems
• Packaging machinery
• Material handling
• Production lines
• Machine tools
• Metal object detection
• Limit-position monitoring
• Automotive manufacturing equipment
