HIMA F6706 Safety Relay Module

Product Description

HIMA F6706 is not a Safety Relay Module. It is a 2-Channel Safety Analog Output Module used in HIMA safety PLC systems such as H41q / H51q. It provides safety-related analog output signals for controlling field devices in Safety Instrumented Systems (SIS).

The module supports 0/4…20 mA analog outputs, with electrically separated channels and safety isolation. It can operate in current source or current sink mode for flexible actuator control.

Specifications

• Brand: HIMA
• Model: F6706 / F 6706
• Product Type: Safety Analog Output Module
• Series: HIMA H41q / H51q Safety PLC System
• Function: Safety-related analog signal output
• Number of Channels: 2 Analog Outputs
• Output Signal:
  • 0…20 mA
  • 4…20 mA
• Output Mode:
  • Current Source
  • Current Sink
• Channel Isolation: Electrically separated outputs
• Resolution: 12-bit
• Safety Application: SIL safety-related systems
• Mounting: HIMA rack installation
• Module Function: Control of valves, actuators, drives and other analog-controlled devices

Advantages & Features

• Safety-rated analog output for critical applications
• Dual-channel independent analog outputs
• High accuracy signal conversion
• Integrated diagnostic and monitoring functions
• Supports flexible 4–20mA field device connections
• Suitable for SIL-rated safety control systems
• Modular design for easy maintenance and replacement

Applications

• Safety Instrumented Systems (SIS)
• Emergency Shutdown Systems (ESD)
• Oil & gas process control
• Chemical processing plants
• Power generation safety systems
• Control valve positioning
• Industrial process automation

Notes

• F6706 is an analog output module, not a relay output module
• Requires compatible HIMA safety PLC hardware
• Confirm output range and wiring configuration before replacement
• Check actuator input requirements (4–20mA / 0–20mA)
• Safety modules should be commissioned according to HIMA procedures
