• • • • • • • • • • • • • • • FOXBORO RH916FJ Termination Assembly







                              Product Overview

                              The Foxboro RH916FJ is a Termination Assembly (TA) used in the Foxboro I/A Series Compact 200 DCS system. It provides the field wiring interface between external instruments and FBM (Fieldbus Module) I/O modules.

                              In simple terms, it is the wiring termination interface board that connects field devices (sensors, transmitters, actuators) to the Foxboro I/O system safely and reliably.

                              ---

                              Key Specifications

                              • Brand: Foxboro (Schneider Electric)
                              • Model: RH916FJ
                              • Type: Termination Assembly (TA module)
                              • System: Foxboro I/A Series / Compact 200
                              • Function: Field wiring interface for FBM modules
                              • Channels: Typically supports multi-channel FBM termination (module dependent)
                              • Signal Types:
                                • Analog (4–20 mA, voltage)
                                • Digital (contact / discrete signals)
                              • Isolation: Channel-to-channel and system isolation via FBM design
                              • Mounting: DIN rail / baseplate mounted termination unit
                              • Connection: FBM module interface cable connection (RH series cable system)
                              • Operating Environment: Industrial / process automation (Class G3 capable system design)

                              ---

                              Advantages & Features

                              • Provides safe and organized field wiring termination
                              • Improves maintenance efficiency (quick module replacement without rewiring field cables)
                              • Strong signal integrity and noise protection
                              • Compatible with Foxboro Compact 200 distributed I/O architecture
                              • Supports analog and discrete signal routing (depending on FBM type)
                              • Designed for harsh industrial environments (oil & gas / power plants)

                              ---

                              Applications

                              • Oil & gas processing plants
                              • Petrochemical industries
                              • Power generation systems
                              • Water treatment plants
                              • Large-scale DCS automation systems
                              • Industrial instrumentation wiring interface

                              ---

                              Precautions

                              • Must be installed with compatible FBM modules and baseplate system
                              • Correct cable type (RH916FJ/RH916 series wiring harness) must be used
                              • Do not mix incompatible termination assembly versions (RH916FJ / RH916FK / RH916XJ differ by wiring type)
                              • Ensure proper grounding and shielding of field cables
                              • Installation must follow Foxboro DCS wiring diagrams
                              • Incorrect wiring may cause signal loss or module failure
