                                                  Foxboro P0916RB Control Module

                                                  Product Overview

                                                  The Foxboro P0916RB is not a Control Module. It is a Fieldbus Baseplate Terminator Module used in the Foxboro I/A Series Distributed Control System (DCS). Its function is to terminate the fieldbus communication segment, reduce signal reflections, and ensure stable communication between Foxboro control processors and FBM I/O modules.

                                                  The P0916RB is used as a passive communication accessory in Foxboro DCS fieldbus networks, commonly installed at the end of a fieldbus segment or baseplate chain.

                                                  ---

                                                  Main Specifications

                                                  • Manufacturer: Foxboro (Invensys / Schneider Electric)
                                                  • Model: P0916RB
                                                  • Series: I/A Series
                                                  • Product Type:
                                                    • Fieldbus Baseplate Terminator
                                                    • HDLC Fieldbus Terminator
                                                    • DCS Communication Accessory
                                                  • Function:
                                                    • Fieldbus signal termination
                                                    • Communication line impedance matching
                                                  • Compatible System:
                                                    • Foxboro I/A Series DCS
                                                    • Foxboro Evo™ DCS



                                                  ---

                                                  Technical Features

                                                  Communication Function

                                                  The P0916RB provides:

                                                  • HDLC fieldbus termination
                                                  • Signal reflection suppression
                                                  • Stable communication between:
                                                    • Control Processor (FCP)
                                                    • Fieldbus Modules (FBM)
                                                    • Baseplate assemblies

                                                  Typical installation:

                                                  Foxboro Controller → Fieldbus Cable → FBM Baseplate → P0916RB Terminator



                                                  ---

                                                  Interface Specifications

                                                  Item	Specification
                                                  Product Type	Fieldbus Terminator
                                                  Communication	HDLC Fieldbus
                                                  Connector	9-pin connector
                                                  Mounting	Foxboro I/A Series baseplate
                                                  Application	DCS communication network



                                                  ---

                                                  Features & Advantages

                                                  • Original Foxboro I/A Series system component
                                                  • Ensures reliable fieldbus communication
                                                  • Reduces communication errors caused by signal reflection
                                                  • Improves DCS network stability
                                                  • Simple installation and replacement
                                                  • Designed for continuous industrial process operation

                                                  ---

                                                  Applications

                                                  Used in:

                                                  • Oil & gas facilities
                                                  • Petrochemical plants
                                                  • Power generation systems
                                                  • Chemical processing plants
                                                  • Water treatment facilities
                                                  • Industrial automation systems

                                                  Typical applications:

                                                  • Foxboro DCS fieldbus network termination
                                                  • FBM module communication chains
                                                  • Control cabinet communication systems
