EMERSON CON041 Interface Module

Emerson CON041 Interface Module (EPRO Eddy Current Signal Converter)





The Emerson CON041 (EPRO series) is an eddy current signal converter / interface module, mainly used in turbomachinery vibration and displacement monitoring systems. It is not a PLC interface module in the usual sense, but a sensor signal conditioning unit that works with Emerson EPRO proximity probes.

It is typically used together with PR6422 / PR6423 / PR6424 proximity sensors for measuring shaft vibration, position, eccentricity, and displacement in rotating machines like turbines, compressors, and pumps.

Key Specifications

• Model: CON041
• Brand: Emerson (EPRO / MMS series)
• Type: Eddy current signal converter / interface module
• Input: Proximity probe signal (e.g., PR6423 series)
• Output signal: Typically -2 to -18 V or 0–10 V / 4–20 mA (system dependent)
• Frequency response: up to 20 kHz class dynamic response
• Supply voltage: approx. -23 V to -32 V DC range
• Mounting: DIN rail
• Operating temperature: about -30°C to +100°C
• Protection: Industrial rugged design (IP20 housing typical)

What it does (simple explanation)

Turbine shaft
↓
Eddy current probe (PR6423)
↓
CON041 Interface Module
↓
Signal conditioning (amplify + convert)
↓
DCS / monitoring system
