Emerson 4195KBE Controller

Product Overview

The Emerson 4195KBE is a Fisher™ 4195KBE Gauge Pressure Indicating Controller. It is a pneumatic pressure controller designed for industrial process control applications. The controller measures process pressure, compares it with the operator-adjusted set point, and outputs a pneumatic control signal to regulate process equipment.

The 4195K series controllers are widely used where reliable pressure indication, control, and monitoring are required, especially in process industries.

Main Specifications

• Manufacturer: Emerson / Fisher Controls
• Model: 4195KBE
• Product Type:
  • Pneumatic Pressure Indicating Controller
  • Process Pressure Controller
  • Industrial Control Instrument
• Controller Type:
  • Proportional + Reset (Two-mode controller)
• Control Medium:
  • Pneumatic air signal
• Measurement:
  • Gauge pressure
• Mounting:
  • Panel mounting
  • Wall mounting
  • Pipestand mounting
  • Actuator mounting

Technical Functions

Pressure Control

The 4195KBE provides:

• Process pressure measurement
• Local pressure indication
• Set point adjustment
• Automatic pressure regulation
• Pneumatic output control signal

Working principle:

Process Pressure → Controller Comparison → Pneumatic Output → Control Valve / Actuator Adjustment

Control Features

Proportional + Reset Control

Features include:

• Proportional control action
• Reset (integral) action
• Direct/reverse acting selection
• Adjustable zero and span
• Operator-adjustable set point

Technical Characteristics

Features & Advantages

• Original Emerson Fisher industrial controller
• Fully pneumatic design, no external power required
• Reliable operation in harsh environments
• Suitable for continuous process control
• Simple adjustment and maintenance
• Resistant to vibration and industrial conditions
• Provides accurate pressure regulation

Applications

Used in:

• Oil & gas facilities
• Refineries
• Chemical plants
• Power generation
• Petrochemical systems
• Industrial process automation

Typical applications:

• Steam pressure control
• Gas pressure regulation
• Compressor control
• Valve actuator control
• Process pressure monitoring
