EATON XTCE115G22TD Contactor

The EATON XTCE115G22TD is a three-pole XT IEC contactor designed for switching and controlling industrial motors and other electrical loads. It has a 115 A continuous current rating and a 24 VDC operating coil. The model includes two normally open and two normally closed auxiliary contacts.

Eaton

+1

Key Technical Specifications

Specifications are based on Eaton XT-series documentation and product references.

Eaton

+1

Features and Advantages

• 115 A current rating for industrial motor-control applications.

• 24 VDC coil for integration with compatible control circuits.

• Auxiliary contacts support electrical interlocking and status feedback.

• Three-pole switching for three-phase loads.

• Screw terminals provide secure electrical connections.

• Designed for industrial control panels and motor starter assemblies.

Typical Applications

• Industrial motor starters

• Pumps, fans, and compressors

• Conveyor and production machinery

• Factory automation systems

• Industrial power switching and control panels

Precautions

• Verify the 24 VDC coil supply before energizing.

• Confirm load current, motor voltage, and utilization category for the application.

• A contactor does not provide complete overload or short-circuit protection by itself; use suitable protective devices.

• Check the auxiliary contact configuration and exact catalog number before ordering.
