Eaton MTL5582 Intrinsically Safe Barrier

Product Overview
The Eaton MTL5582 is a single-channel intrinsically safe resistance isolator in the MTL5500 series. It connects to an RTD or other resistance sensor in a hazardous area, provides galvanic isolation, and repeats the resistance signal to a safe-area monitoring system. It is typically used with Pt100 3-wire RTDs.

Technical Specifications

• Model: MTL5582
• Type: Intrinsically Safe Resistance Isolator
• Channels: 1
• Input: 2-, 3-, or 4-wire RTD / resistance
• Typical Sensor: Pt100
• Hazardous Area: Zone 0, IIC, T4
• Power Supply: 20–35 VDC
• RTD Excitation: 200 µA
• Output Range: 10–400 Ω
• Galvanic Isolation: 250 V RMS
• Mounting: 35 mm DIN rail
• Operating Temperature: -20 to +60°C
• Power Indicator: Green LED

Advantages & Features

• Intrinsically safe interface for hazardous-area RTD signals
• Galvanically isolates field and safe-area circuits
• Supports 2-, 3-, and 4-wire RTD connections
• Suitable for Pt100 temperature measurement
• Open-circuit sensor detection with upscale output
• Compact DIN-rail mounting design

Applications

• Oil & gas
• Petrochemical plants
• Chemical processing
• Process temperature monitoring
• Hazardous-area instrumentation
• Industrial process control
