EATON HMI 03 XV-102-B6-35TQR-1AL-PLC HMI Operator Panel

The EATON XV-102-B6-35TQR-1AL-PLC is a compact HMI-PLC operator panel from Eaton’s XV100 series. It combines a color touchscreen, visualization functions, PLC capabilities, and communication interfaces in one unit for industrial machine control. The closely related official XV-102-B6-35TQR-10-PLC model is documented by Eaton.

Eaton

+2

Key Technical Specifications

Specifications are based on Eaton’s XV-102 documentation and related model information. Confirm the exact 1AL suffix against the device nameplate before listing, as it differs from the documented -10-PLC model.

Eaton

+2

Features and Advantages

• Combines operator visualization and PLC functionality in a compact unit.

• Color touchscreen supports intuitive machine operation.

• Ethernet and serial communication support integration with industrial equipment.

• Fanless design uses passive cooling.

• Front-panel IP65 protection suits industrial control cabinets.

• Supports compatible Eaton engineering and visualization software.

Typical Applications

• Industrial machine control

• Packaging and production equipment

• Small automation systems

• Process monitoring and operator interfaces

• Factory control panels

Precautions

• Verify the exact model suffix and hardware revision before ordering.

• Confirm software, PLC program, and communication compatibility with the existing system.

• Use a suitable regulated 24 VDC power supply.

• Protect the rear of the panel from dust and moisture; its protection rating is lower than the front.

• Check whether programming software, cables, and mounting accessories are included.
