Eaton HFDDC3100L Circuit Breaker

Eaton HFDDC3100L Circuit Breaker (Molded Case Circuit Breaker – PV / DC Series)





The Eaton HFDDC3100L is a molded case circuit breaker (MCCB) from Eaton’s Series C / PVGuard (solar / DC-rated protection) line. It is used for protecting electrical circuits against overload and short-circuit faults, especially in industrial and DC/solar applications.

Product Information

• Brand: Eaton (USA)
• Model: HFDDC3100L
• Type: Molded Case Circuit Breaker (MCCB)
• Frame: F-frame
• Poles: 3-pole
• Rated current: 100A
• Voltage rating: 600 VAC / 250 VDC
• Interrupt rating: up to 42 kAIC @ 600 VAC
• Standard: UL 489 certified

What it actually is

This is a heavy-duty protective switch, meaning:

• Automatically trips when overload or short circuit occurs
• Protects cables, equipment, and power systems
• Can be used in DC solar systems or industrial AC distribution panels
• Works as a main protection device in power distribution systems

System Role (Simple)

Power source (AC/DC supply)
→ Eaton MCCB (this unit)
→ electrical distribution line
→ loads (drives, PLC panels, machines, etc.)

So it acts like a “high-level safety protection switch for power systems.”

Key Features

• Thermal + magnetic trip protection
• High breaking capacity (industrial fault protection)
• Suitable for AC and DC systems
• Rugged molded case design
• DIN/panel mounted installation
• Designed for continuous industrial duty

Typical Applications

• Industrial power distribution panels
• Motor control centers (MCC)
• Solar PV DC protection systems
• Factory electrical systems
• Heavy machinery power input protection
• UPS and battery systems

Advantages

• High fault interruption capability
• Reliable long-term protection
• Suitable for harsh industrial environments
• Supports both AC and DC applications
• UL certified safety standard

Important Notes

• Not PLC module ❌
• Not controller ❌
• Not sensor ❌
• Not communication device ❌
• It is a power protection circuit breaker (MCCB) ✔

Precautions

• Must match correct system voltage (AC/DC rating critical)
• Requires proper torque tightening on terminals
• Must be installed in approved electrical panel
• Not interchangeable with different frame sizes or brands
• Incorrect selection can cause safety risk
