Eaton 257902 XIOC-2AO-U1-2AO-I2 Analog Output Module

Product Type: Analog Output Module
Model: XIOC-2AO-U1-2AO-I2
Catalog No.: 257902
Series: XIOC / XC100-XC200
Manufacturer: Eaton

The Eaton 257902 XIOC-2AO-U1-2AO-I2 is a compact 4-channel analog output module for Eaton XC100/XC200 modular PLC systems. It provides 2 voltage outputs (0–10 V DC) and 2 current outputs (4–20 mA) with 12-bit resolution, making it suitable for proportional control and industrial process applications.

Technical Specifications

Eaton specifies that the module's voltage and current outputs can be used simultaneously.

Advantages & Features

• 4 Analog Outputs — Provides 2 voltage and 2 current channels in one compact module.
• 0–10 V Output — Suitable for drives, valves, actuators and proportional control devices.
• 4–20 mA Output — Ideal for industrial process-control instruments.
• 12-Bit Resolution — Provides precise analog signal generation.
• Fast Conversion — Conversion time of ≤5 ms.
• Simultaneous Output Types — Voltage and current outputs can operate at the same time.
• Opto-Isolated Channels — Provides isolation between output circuitry and internal electronics.
• Compact 30 mm Width — Helps save control-panel space.
• XC100/XC200 Compatibility — Designed for Eaton modular PLC expansion systems.

Typical Applications

• Industrial automation
• PLC analog signal control
• Variable frequency drive speed reference
• Proportional valve control
• Motor speed control
• Process control
• Temperature and pressure control
• Flow control
• Packaging machinery
• Production lines
• Factory automation
