EATON 1775KTPMPP1700 Control Module

EATON 1775KT-PMPP-1700 PanelMate Power Pro 1700 Operator Interface

Correction: This is not a generic Control Module. The EATON / Cutler-Hammer 1775KT-PMPP-1700 is a PanelMate Power Pro 1700 Operator Interface / HMI panel. The part number is also commonly written as 1775KTPMPP1700, with associated P/N 92-01940-02.

The available product references identify this unit as a 1700 Series PanelMate operator interface, rated at approximately 1.1 A / 23 W / 24 VDC.

Advantages & Features

• PanelMate Power Pro industrial operator interface
• Designed for machine and process monitoring/control
• 24 VDC industrial power supply
• Supports industrial PLC communication
• Used with PanelMate programming/application software
• Suitable for legacy automation-system replacement and maintenance

Historical field documentation also identifies the 1775KTPMPP1700 as a PanelMate unit communicating with PLC systems such as GE Fanuc Series 90-70.

Typical Applications

• Industrial machine HMI
• Factory automation
• PLC operator stations
• Process monitoring
• Manufacturing equipment
• Legacy control-system upgrades and replacement
