Bently Nevada 330180-51-05 3300 XL 8 mm Proximitor Assembly

1. Product Introduction

Model Code Decoding

2. Core Technical Specifications

Measurement Performance

• Linear range: 0 to 200 μm (0–8 mil)
• Standard slope: 7.874 V/mm (200 mV/mil)
• Linearity error: ≤ ±1.5% FS
• Frequency response: DC ~ 10 kHz, suitable for high-speed rotor vibration test
• Recommended target material: Carbon steel; correction coefficient required for stainless steel, aluminum alloy, brass

Electrical Parameters

• Power supply: -18 VDC ~ -24 VDC negative DC power
• Typical operating current: 12 mA
• Output signal: Negative DC voltage proportional to probe-target gap
• Built-in fault detection logic: Identify open circuit, short circuit and probe loss; output fault voltage to trigger system alarm
• No external signal conditioner required, direct connection to Bently 3500 monitor modules

Mechanical & Environmental

• Integral cable length: 5 m
• Probe interface: 2-pin microdot connector
• Power/output side: Screw terminal block wiring
• Mounting: Supports DIN rail or panel bracket installation
• Operating temperature: -30°C ~ +70°C
• Storage temperature: -40°C ~ +85°C
• Humidity: 5% ~ 95% RH, non-condensing
• Approvals: ATEX / IECEx Zone 2, CSA Class I Div 2 for hazardous industrial areas

3. Matching System Components

1. Eddy current probe: 330103 / 330104 / 330105 series 8 mm probes
2. Extension cable: 330130 series (for distance extension between probe and proximitor)
3. Monitoring rack: Bently Nevada 3500 machinery protection rack
4. Compatible monitor modules:
   • 3500/40 Vibration Monitor
   • 3500/42 Axial Position Monitor
5. Configuration software: 3500 Rack Configuration Software

4. Working Principle

1. Output high-frequency RF excitation signal to the eddy current probe tip;
2. Eddy current generates on the metal rotating target surface;
3. The proximitor demodulates RF signal and converts gap distance into linear DC voltage;
4. Transmit voltage signal to rack monitor for real-time calculation of shaft vibration, axial thrust displacement and rotational speed;
5. Continuously self-diagnose cable and probe faults, upload fault status to monitoring system.

5. Key Advantages

1. Mature 3300 XL series, widely adopted standard for rotating machinery protection in energy and petrochemical industries;
2. 10 kHz wide frequency response, accurately capture high-frequency rotor vibration signals;
3. 5m integrated cable reduces wiring joints and minimizes signal interference;
4. Complete cable break/short-circuit diagnosis for fast field troubleshooting;
5. Strong anti-EMI capability, stable operation near large motors, inverters and high-power equipment;
6. Wide temperature tolerance adapts to power plants, refineries and offshore control cabinets.

6. Typical Application Scenarios

• Vibration & axial thrust monitoring of steam turbines, gas turbines;
• Condition protection for centrifugal compressors, large pumps and blowers;
• Generator bearing vibration monitoring in thermal power plants;
• Critical rotating equipment safety monitoring for refineries and offshore oil & gas platforms;
• Petrochemical high-speed rotating machinery interlock protection systems;
• Full set machinery protection systems matched with Bently Nevada 3500 rack.
