Product Description
Bently Nevada 3500/22 288055-01 is a 3500/22 Transient Data Interface (TDI) Module designed for the 3500 Machinery Protection System. It serves as the communication interface between the 3500 rack system and Bently Nevada monitoring software, providing data collection, rack configuration, and Ethernet communication functions.

The TDI combines the functions of the 3500/20 Rack Interface Module (RIM) with advanced data collection capabilities. It continuously collects steady-state and transient waveform data from compatible monitor modules and transfers data to host software such as System 1 Condition Monitoring Software.

Technical Parameters

• Brand: Bently Nevada
• Model: 3500/22 288055-01
• Product Type: Transient Data Interface Module (TDI)
• System: 3500 Machinery Protection System
• Module Function: Rack interface / Data acquisition / Communication interface
• Module Position: Slot 1 of 3500 rack (next to power supplies)
• Communication Interface: Ethernet via I/O module
• Front Interface: USB port for configuration
• Data Collection:
  • Steady-state data
  • Transient dynamic waveform data (with enabled channels)
• Compatible Software: System 1 Condition Monitoring Software, 3500 System Configuration Software
• Power Consumption: Approx. 10.5 W
• Operating Temperature: -30°C to +65°C
• Module Type: Half-height rack module
• Country of Origin: USA (commonly supplied configuration)

Advantages & Features

• Original Bently Nevada 3500 series monitoring module
• Provides communication between rack hardware and monitoring software
• Supports continuous machinery condition data collection
• Enables vibration and transient waveform analysis
• Front USB port allows convenient system configuration
• Ethernet communication for remote monitoring integration
• Improves predictive maintenance capability for critical equipment
• Designed for high-reliability industrial applications

Applications

• Steam turbine monitoring systems
• Gas turbine protection systems
• Compressor condition monitoring
• Generator vibration monitoring
• Large rotating machinery protection
• Industrial predictive maintenance systems
• Bently Nevada 3500 rack-based monitoring installations

Notes

• 3500/22 288055-01 is a Transient Data Interface Module, not a measurement input module.
• Requires a compatible 3500 rack, power supply module, monitor modules, and I/O module to operate.
• Confirm the I/O module type and communication configuration before replacement.
• Ensure firmware and configuration compatibility when replacing an existing module.
• Installation should follow Bently Nevada 3500 system configuration requirements.
