BENTLY 3500/22 146031-01 Monitoring Module

BENTLY 3500/22 146031-01 Monitoring Module

Product Description
Bently Nevada 3500/22 146031-01 is a 3500/22M Transient Data Interface (TDI) I/O Module designed for the 3500 Machinery Protection System. It provides the communication interface between the 3500 monitoring rack and Bently Nevada condition monitoring software, enabling continuous collection and transmission of machinery monitoring data.

The module combines the functions of a 3500/20 Rack Interface Module (RIM) and a communication processor, allowing the 3500 system to connect with System 1 Condition Monitoring and Diagnostic Software for machinery health analysis.

Technical Parameters

• Brand: Bently Nevada
• Model: 3500/22
• Part Number: 146031-01
• Product Type: Transient Data Interface (TDI) I/O Module
• Series: 3500 Machinery Protection System
• Function: Rack communication interface / Data acquisition module
• Communication Interface: 10Base-T / 100Base-TX Ethernet
• Data Collection:
  • Static operating data
  • Dynamic waveform data (with optional channel enabling function)
• Compatible Modules: 3500 M-Series monitors (such as 3500/40M, 3500/42M)
• Installation Position: Slot 1 of 3500 rack (next to power supply module)
• Operating Temperature: -30°C to +65°C
• Storage Temperature: -40°C to +85°C
• Humidity: Up to 95% RH, non-condensing
• Power Supply: Rack supplied

Advantages & Features

• Original Bently Nevada 3500 series communication module
• Provides reliable connection between monitoring rack and host software
• Supports continuous machinery condition data collection
• Enables vibration and transient waveform analysis
• Ethernet communication for remote monitoring integration
• Improves predictive maintenance and fault diagnosis capability
• Modular design for easy installation and replacement
• Designed for critical rotating machinery monitoring systems

Applications

• Steam turbine monitoring systems
• Gas turbine protection systems
• Compressor condition monitoring
• Generator vibration analysis
• Pump and motor monitoring
• Industrial rotating equipment protection
• Predictive maintenance systems

Notes

• 146031-01 is a TDI I/O communication module, not a vibration input measurement module.
• Requires a complete Bently Nevada 3500 rack system, including power supply and monitoring modules.
• Confirm rack configuration and firmware compatibility before replacement.
• For transient waveform recording, verify whether the system requires the optional channel enabling function.
