BENTLY 3500/15-05-05-00 Power Supply Module

3500/15-05-05-00
3500/15-05-05-00

BENTLY 3500/15-05-05-00 Power Supply Module

BENTLY 3500/15-05-05-00 Power Supply Module

  • Item NO.:

    3500/15-05-05-00

  • Payment:

    T/T

  • Price:

    $840

  • Product Origin:

    USA

  • Color:

    NEW

  • Goods stock:

    3

  • Product weight:

    0.23KG

  • Lead Time:

    In stock
Inquire Now

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

                                                                                                                                                                                                                              • BENTLY NEVADA 3500/15-05-05-00 Power Supply Module

                                                                                                                                                                                                                                Specification Details
                                                                                                                                                                                                                                Brand Bently Nevada
                                                                                                                                                                                                                                Model 3500/15-05-05-00
                                                                                                                                                                                                                                Product Name 3500/15 Power Supply Module
                                                                                                                                                                                                                                Product Type AC Power Supply Module
                                                                                                                                                                                                                                System Bently Nevada 3500 Machinery Protection System
                                                                                                                                                                                                                                Top Slot Supply -05 Universal AC
                                                                                                                                                                                                                                Bottom Slot Supply -05 Universal AC
                                                                                                                                                                                                                                AC Input Voltage 85–264 VAC RMS
                                                                                                                                                                                                                                Nominal Input 110–220 VAC
                                                                                                                                                                                                                                Input Frequency 47–63 Hz
                                                                                                                                                                                                                                Maximum Input Current 2.8 A RMS
                                                                                                                                                                                                                                Input Peak Voltage 120–373 V peak
                                                                                                                                                                                                                                Agency Approval -00 None
                                                                                                                                                                                                                                Front Indicator Supply OK LED
                                                                                                                                                                                                                                Installation Left-side power supply slots of 3500 rack
                                                                                                                                                                                                                                Dimensions Approx. 120.7 × 50.8 × 251.5 mm
                                                                                                                                                                                                                                Weight Approx. 1.39 kg
                                                                                                                                                                                                                                Operating Temperature -30°C to +65°C
                                                                                                                                                                                                                                Storage Temperature -40°C to +85°C
                                                                                                                                                                                                                                Humidity Up to 95%, non-condensing

                                                                                                                                                                                                                                Key Technical Specifications

                                                                                                                                                                                                                                • 3500/15 power supply for Bently Nevada 3500 machinery protection systems

                                                                                                                                                                                                                                • Dual universal AC configuration: -05 top slot + -05 bottom slot

                                                                                                                                                                                                                                • Wide 85–264 VAC RMS input range

                                                                                                                                                                                                                                • 47–63 Hz input frequency

                                                                                                                                                                                                                                • Maximum input current approximately 2.8 A RMS

                                                                                                                                                                                                                                • Front-panel SUPPLY OK status indicator

                                                                                                                                                                                                                                • Designed for installation in the left side of the 3500 rack

                                                                                                                                                                                                                                • Supports redundant power-supply configurations for high-availability systems

                                                                                                                                                                                                                                Advantages & Features

                                                                                                                                                                                                                                • Wide-range AC input simplifies international installation

                                                                                                                                                                                                                                • Dual power-supply configuration supports system redundancy

                                                                                                                                                                                                                                • Front LED provides quick operating-status indication

                                                                                                                                                                                                                                • Designed specifically for the Bently Nevada 3500 platform

                                                                                                                                                                                                                                • Suitable for continuous industrial machinery-monitoring applications

                                                                                                                                                                                                                                Applications

                                                                                                                                                                                                                                • Turbine monitoring

                                                                                                                                                                                                                                • Compressor protection

                                                                                                                                                                                                                                • Generator monitoring

                                                                                                                                                                                                                                • Pump and motor protection

                                                                                                                                                                                                                                • Industrial machinery condition monitoring

                                                                                                                                                                                                                                • Bently Nevada 3500 Machinery Protection Systems

                                                                                                                                                                                                                                Precautions

                                                                                                                                                                                                                                • Verify that the rack is configured for the 3500/15 power supply family.

                                                                                                                                                                                                                                • Confirm the input voltage is within 85–264 VAC RMS.

                                                                                                                                                                                                                                • The -05/-05 configuration represents two universal AC supply positions; verify that the required Power Input Modules are included.

                                                                                                                                                                                                                                • Do not mix the universal AC power supply/PIM with incompatible legacy 3500 AC power-supply components.

                                                                                                                                                                                                                                • Disconnect power before installing or removing the module.

                                                                                                                                                                                                                                • Verify grounding and cabinet wiring according to the Bently Nevada installation requirements.

The structure and details of the product：
