BENTLY 330130-040-00 Extension Cable

Product Description

BENTLY NEVADA 330130-040-00 is a 3300 XL Standard Extension Cable used in the 3300 XL Proximity Transducer System. It connects the proximity probe and the Proximitor® Sensor, extending the sensor installation distance while maintaining accurate eddy-current displacement and vibration measurement signals.

This extension cable is commonly used together with Bently Nevada 3300 XL 8 mm proximity probes and Proximitor sensors for monitoring shaft vibration, axial position, and radial displacement of rotating machinery.

Specifications

• Brand: BENTLY NEVADA
• Model: 330130-040-00
• Product Type: Extension Cable
• Series: 3300 XL
• Application: Proximity Transducer System
• Cable Length: 4.0 m (13.1 ft)
• Cable Type: Standard cable
• Connector Type: Miniature coaxial ClickLoc connector
• Cable Material: 75Ω triaxial FEP insulated cable
• Capacitance: Approx. 69.9 pF/m
• Operating Temperature: Approx. -52°C to +177°C
• Weight: Approx. 0.14 kg
• Installation: Connects probe and Proximitor sensor

Model Code Explanation

330130-040-00

• 330130 → 3300 XL Standard Extension Cable
• 040 → Cable length: 4.0 meters
• 00 → Standard cable configuration
• 00 → No special agency approval option

Advantages & Features

• Designed specifically for Bently Nevada 3300 XL systems
• Maintains accurate vibration and displacement signal transmission
• High resistance to industrial environments
• FEP insulation provides excellent temperature and chemical resistance
• Compatible with 3300 XL 8 mm proximity measurement systems
• Supports reliable machinery condition monitoring

Applications

• Steam turbine vibration monitoring
• Gas turbine protection systems
• Compressor condition monitoring
• Generator shaft displacement measurement
• Pump and motor vibration monitoring
• Rotating machinery predictive maintenance systems

Notes

• 330130-040-00 is an extension cable only, not a complete sensor system
• Requires matching:
  • Bently Nevada proximity probe
  • Proximitor sensor
• Total electrical system length (probe + extension cable + sensor configuration) must match the required system length
• Confirm connector type and cable length before replacement
• Avoid sharp bending or mechanical damage during installation
