BENTLY 106M1079-01 Cable Assembly

BENTLY NEVADA 106M1079-01 Cable Assembly

The 106M1079-01 is a Cable Assembly (Wiring Harness) used in the Bently Nevada 3500 Series Machinery Protection System, typically associated with the 3500/15 Power Supply Module system.

Basic Information

• Part Number: 106M1079-01
• Brand: Bently Nevada (Baker Hughes)
• Series: 3500 System
• Type: Cable Assembly / Power System Harness
• Function: Connects power supply module and system backplane / power distribution interface

Technical Description

The 106M1079-01 cable assembly is used within the 3500/15 power architecture, providing:

• Electrical connection between power supply module and rack system
• Stable transmission of DC power and control signals
• Support for redundant power configuration (dual power supplies)
• Reliable operation of full 3500 monitoring rack

It is part of the internal wiring system ensuring the 3500 rack remains continuously powered and stable.

Key Features

• OEM industrial-grade cable design
• High reliability for 24/7 continuous operation
• Strong resistance to EMI (electromagnetic interference)
• Designed specifically for Bently Nevada 3500 system compatibility
• Supports redundant power supply architecture
• Stable power distribution for all rack modules

Application Areas

• Power plants (steam & gas turbines)
• Oil & gas facilities
• Petrochemical industries
• Compressor and pump monitoring systems
• Refinery and heavy industrial automation systems
• Critical rotating machinery protection systems

System Role (Important)

In the 3500/15 system, this cable assembly is part of the power delivery chain, ensuring:

• Stable AC/DC conversion output distribution
• Communication between power modules and rack backplane
• Continuous operation of monitoring and protection modules
• Support for redundant power supply operation

Without this cable assembly, the 3500 rack power system cannot operate reliably or may lose redundancy protection.

Advantages

• Ensures stable and safe system power distribution
• Reduces risk of system shutdown due to wiring faults
• OEM matching ensures perfect compatibility
• Designed for harsh industrial environments
• Long service life with industrial insulation materials

Precautions

• Must be used only with Bently Nevada 3500/15 system
• Do not substitute with generic industrial cables
• Ensure connectors are fully seated and locked
• Avoid bending or tension near connector joints
• Install only in de-energized system conditions
