B&R 5AP1120.1043-C01 Operator Panel



Product Overview

The B&R 5AP1120.1043-C01 is a 10.4-inch industrial operator panel (HMI) from the B&R Automation Panel 1000 series. It is designed for machine visualization and operator control in industrial automation systems.

This panel is typically used together with B&R PPC / IPC controllers, acting as a visualization interface (not a standalone PLC/PC).

Key Specifications

• Brand: B&R (Bernecker + Rainer)
• Model: 5AP1120.1043-C01
• Series: Automation Panel 1000 (AP1000)
• Type: Industrial HMI / Operator Panel
• Display: 10.4" TFT color LCD
• Resolution: 640 × 480 (VGA)
• Touch Type: Analog resistive single-touch
• Color Depth: 16.7 million colors
• Backlight: LED (long life design)
• Protection: Front IP65 / UL Type 4X
• Mounting: Panel-mounted (cabinet installation)
• Interface: USB (front service interface), system link module connection
• System Requirement: Works with B&R PPC / Panel PC / IPC system (not standalone)

Advantages & Features

• Stable industrial HMI visualization platform
• High brightness LED backlight for long-term use
• Rugged IP65 front protection for harsh environments
• Reliable resistive touch for gloves / industrial operation
• Modular design compatible with B&R control systems
• Long lifecycle support for legacy and current machines

Applications

• Industrial machine control panels
• Packaging machinery
• Printing and labeling systems
• CNC and automation equipment
• Production line operator stations
• B&R PPC / IPC based control systems

Precautions

• This is not a standalone PLC or computer
• Requires compatible B&R controller (PPC / IPC / Automation PC)
• Correct system link module must be installed for operation
• Avoid using incompatible cable or display interface
• Ensure proper grounding for stable touchscreen performance
• Install in a properly sealed cabinet to maintain IP65 protection
