AI810-eA Analog Input Module (Industrial-Grade High-Precision Analog Signal Acquisition for Process Control Systems)

The AI810-eA is a high-performance industrial analog input module designed to accurately collect and convert analog signals from industrial sensors and transmitters into digital data for PLC/DCS systems. It features 8 independent analog input channels, supporting a wide range of industrial signal types: 4-20mA DC, 0-20mA DC, 0-10V DC, and thermocouple/RTD signals (e.g., Pt100, K-type). With ultra-high measurement accuracy (±0.05% of full scale) and low temperature drift (≤20ppm/℃), it ensures reliable data acquisition even in fluctuating industrial environments. The module provides 3kVrms galvanic isolation between channels and from the backplane, eliminating ground loops and resisting electromagnetic interference (EMI). Compatible with Profinet, Modbus-TCP, and Ethernet/IP protocols, it is widely used in process control, environmental monitoring, and manufacturing systems requiring precise analog measurement.

This module adopts a compact, rugged design with a metal housing for enhanced durability in harsh industrial settings. It supports 35mm standard DIN rail mounting for easy integration into control cabinets, while its high-precision 24-bit ADC (Analog-to-Digital Converter) ensures detailed signal resolution. Each channel is configurable via software for different signal types, eliminating the need for hardware adjustments. Built-in signal conditioning and filtering circuits reduce noise interference, while surge protection (2kV ESD, 4kV EFT) safeguards against transient voltage spikes. The front panel features LED indicators for module power, communication status, and channel faults, enabling quick visual diagnostics. It supports hot-swappable installation (with compatible backplanes) for maintenance without system shutdown, reducing downtime in critical processes. Operating within a temperature range of -30℃~+70℃, it complies with IEC 61131-2 and EN 61000-6-2 standards for industrial EMC and safety.

① Ultra-High Accuracy: ±0.05% full-scale accuracy ensures precise measurement of critical process variables; ② Multi-Signal Compatibility: Supports current, voltage, RTD, and thermocouple signals for versatile applications; ③ Enhanced Isolation: 3kVrms isolation eliminates ground loops in complex industrial environments; ④ Flexible Configuration: Software-configurable channels adapt to different signal types without hardware changes; ⑤ Hot-Swappable Design: Enables maintenance without system shutdown, minimizing downtime; ⑥ Wide Temperature Range: -30℃~+70℃ operation suits extreme industrial conditions.

① Process Industry: Measurement of pressure, flow, level, and temperature in chemical, oil & gas plants; ② Manufacturing: Monitoring of temperature, humidity, and pressure in production lines (e.g., automotive, semiconductor); ③ Energy Sector: Acquisition of current, voltage, and temperature signals in power generation and distribution systems; ④ Environmental Monitoring: Measurement of air quality, water flow, and temperature in environmental control systems; ⑤ Food & Beverage: Monitoring of temperature, pressure, and level in food processing and packaging lines.

① Ensure signal types are correctly configured in software to match connected sensors/transmitters; ② Use shielded twisted-pair cables for signal lines and connect shields to protective ground to reduce EMI; ③ Avoid exceeding the maximum input range for each signal type to prevent damage to input circuits; ④ When connecting thermocouples, use compensation cables to minimize temperature measurement errors; ⑤ During hot-swap operations, follow system-specific procedures to avoid transient voltage spikes; ⑥ Install in a well-ventilated area away from heat sources exceeding 70℃; ⑦ Regularly calibrate the module (per manufacturer recommendations) to maintain measurement accuracy
