ABB ZAF75-70 contactorv

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB ZAF75-70 is a replacement coil module designed for ABB’s AF-series contactors (e.g. AF45 to AF75, and AF50N2 to AF75N3). It supports a wide control voltage range of 100 V to 250 V in either AC or DC mode.

This coil module is installed on the contactor and is responsible for energizing and de-energizing the main contacts of the contactor.

Key Technical Specifications

Advantages & Features

1. Wide Voltage Compatibility
   The coil supports a broad voltage range (100 V to 250 V AC or DC), making it adaptable to various control systems and power environments.

2. Modular & Replaceable Design
   As a standalone coil module, the ZAF75-70 can be replaced swiftly without changing the entire contactor. This simplifies maintenance and spare parts management.

3. High Reliability & Brand Assurance
   As an ABB original component, it offers dependable performance and ensures compatibility with ABB contactors.

4. Standards Compliance
   Meets international electrical standards (UL, IEC, CSA, etc.), suitable for industrial-grade installations.

5. Cost Efficiency
   When the contactor's mechanical parts are still good and only the coil fails, replacing the coil is significantly more economical than replacing the entire contactor.

Application Fields

The ZAF75-70 coil is used widely in industrial automation and power control systems. Typical application areas include:

• Motor control and motor starters

• Switching control in industrial production lines

• Control of machines such as lathes, pumps, compressors

• Applications inside distribution panels or control cabinets

• Any system requiring remote or automated switching via AF-series contactors

Essentially, wherever an AF-series contactor is used to control a main power circuit, the ZAF75-70 coil may serve as its drive coil.

Precautions & Notes for Use

1. Select the Correct Voltage Rating
   Although the coil supports 100–250 V, the control voltage in your system must fall within that range for reliable operation and to avoid over-stressing the coil.

2. Polarity & Wiring
   For DC usage especially, correct wiring and polarity are important. Wrong polarity may prevent proper functioning of the coil circuit.

3. Ambient Temperature & Heat Dissipation
   Avoid operating in extreme temperatures. The overall contactor (including coil) is typically rated for –40 °C to +70 °C (depending on the contactor model). If used under extreme conditions, ensure adequate heat dissipation or protection.

4. Avoid Frequent Switching
   While the coil is built for many operations, excessively frequent ON/OFF switching can accelerate wear, cause electromagnetic stress, and shorten its life.

5. Storage & Installation Precautions

   • Store in dry, dust-free, low-humidity conditions; avoid rapid temperature changes that cause condensation.

   • During installation/removal, handle gently to prevent mechanical shock, static damage, or deformation.

   • Ensure proper, secure wiring; avoid loose or poor contacts.

   • Before use, inspect for short circuits or leakage currents.

6. Compatibility with the Contactor
   Though ZAF75-70 is intended as a replacement for AF45–AF75 series, verify that the specific contactor model physically and electrically supports that coil (matching slot, dimensions, mounting mechanism, insertion orientation, etc.).
