ABB YYT102Q Servo Control Board

1. Product Overview

The ABB YYT102Q Servo Control Board is a key electronic module in ABB industrial robots and automation systems, used for controlling servo motors and processing drive signals. It provides precise position, speed, and torque control and communicates with other control modules at high speed to ensure smooth operation of robots and automation equipment.

The YYT102Q is designed with industrial-grade reliability, high noise immunity, and long service life, suitable for continuous operation in industrial automation environments.

2. Technical Specifications

General

• Model: YYT102Q

• Type: Servo Control Board

• Compatible Systems: ABB S4 / S4C / S4C+ robot controllers

• Function: Servo motor position, speed, and torque control; I/O signal processing

Electrical Characteristics

• Operating Voltage: 24 V DC / 5 V DC (supplied by controller)

• I/O Interface: Digital I/O, Analog I/O, Encoder interface

• Communication: High-speed internal control bus

• Control Accuracy: ±0.1% (typical)

• Response Time: < 2 ms

• Protection: Overvoltage, overcurrent, short-circuit, reverse polarity

Mechanical & Environmental

• Mounting: Rack-mounted or panel-fixed

• PCB: Industrial-grade multilayer, heat and vibration resistant

• Operating Temperature: 0°C to +55°C

• Storage Temperature: –25°C to +70°C

• Humidity: 5%–95%, non-condensing

• Protection Class: IP20

Dimensions & Weight

• Dimensions (L×W×H): ~200 × 120 × 30 mm

• Weight: ~0.6 kg

3. Features & Advantages

• High-precision servo control for position, speed, and torque

• Fast real-time response for servo and I/O signals

• Industrial-grade reliability: vibration and temperature resistant

• Multi-functional interface: encoder signals, digital/analog I/O

• Modular design for easy installation and maintenance

• Built-in protection: overvoltage, overcurrent, short-circuit, reverse polarity

4. Application Areas

• ABB industrial robot servo drive control

• Automated production line servo motor control

• High-precision robotic arms, handling, welding, and assembly systems

• CNC system servo drive and feedback control

• Industrial automation motion control

• Robot system monitoring and fault diagnostics

5. Precautions

• Disconnect controller and system power before installation or removal.

• Use ESD protection (e.g., wear anti-static wrist strap) during handling.

• Avoid high humidity, dust, and corrosive environments.

• Ensure connectors and terminals are secure to prevent poor contact.

• Do not disassemble or modify internal components.

• Regularly inspect the board and connectors to ensure stable operation.
