ABB XVC768AE102 analog input module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB XVC768AE102 Analog Input Module – Product Information

1. Product Overview

The ABB XVC768AE102 Analog Input Module is an advanced signal acquisition device designed for ABB control systems. It converts analog process signals such as current, voltage, temperature, and pressure into digital data for the CPU to process and control.
With high precision, strong noise immunity, and robust isolation design, this module ensures reliable performance in industrial automation and process control environments.

2. Technical Specifications

• Model: XVC768AE102

• Type: Analog Input Module

• Input Channels: 8 isolated analog inputs

• Input Signal Types:

  • Current: 0–20 mA / 4–20 mA

  • Voltage: 0–10 V / 1–5 V

• Resolution: 16-bit A/D conversion

• Sampling Rate: Up to 1000 samples per second per channel

• Input Impedance: > 250 kΩ (voltage), < 250 Ω (current)

• Isolation: Optical isolation between channels and system bus

• Channel-to-channel Isolation Voltage: 500 V DC

• Accuracy: ±0.1% Full Scale

• Common-Mode Rejection Ratio (CMRR): > 100 dB

• Power Supply: 24 V DC ±10%

• Power Consumption: Approx. 5 W

• Signal Filtering: Software-configurable low-pass filter

• Connection Type: Screw or pluggable terminal blocks

• Protection Degree: IP20

• Mounting: DIN rail mounting

• Operating Temperature: -20 ℃ to +60 ℃

• Storage Temperature: -40 ℃ to +85 ℃

• Humidity: 5%–95% non-condensing

• Dimensions: Approx. 120 × 100 × 60 mm

• Weight: Approx. 0.35 kg

• Compliance: IEC 61131-2, CE, UL, RoHS

3. Features and Advantages

1. High precision 16-bit A/D conversion for accurate signal capture.

2. Versatile signal compatibility with current and voltage inputs.

3. Strong electrical isolation for stable and safe operation.

4. Excellent noise immunity suited for harsh industrial environments.

5. Modular design enabling easy installation and system expansion.

6. Built-in diagnostic functions for real-time fault detection.

4. Application Areas

• Analog signal acquisition in DCS/PLC systems

• Industrial automation and process monitoring

• Electrical power systems and energy analysis

• Chemical and petrochemical process control

• Water treatment and environmental monitoring

• Intelligent manufacturing and energy management

5. Precautions

1. Verify signal type and input range before wiring.

2. Ensure correct power supply polarity.

3. Use shielded cables and keep signal lines away from power circuits.

4. Do not insert or remove the module while powered.

5. Regularly check wiring and terminal tightness.

6. Use protective enclosures in high-humidity or dusty environments.
