ABB XK08F1-A3.0 Analog Input/Output Expansion Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB XK08F1-A3.0 Analog Input/Output Expansion Module is designed for ABB industrial automation systems to expand analog input and output channels of controllers. It collects multiple voltage and current signals and outputs analog control signals, providing precise and reliable data acquisition and control for industrial process systems. The XK08F1-A3.0 module works with ABB DCS, PLC, and other controllers to enable flexible system expansion and high-performance control.

2. Technical Specifications

• Model: XK08F1-A3.0

• Product Type: Analog Input/Output Expansion Module

• Function: Collects analog signals and outputs analog control signals

• Input Types:

  • Voltage input: 0–10 V DC

  • Current input: 0–20 mA / 4–20 mA

• Output Types:

  • Voltage output: 0–10 V DC

  • Current output: 0–20 mA / 4–20 mA

• I/O Channels: 8 analog inputs / 8 analog outputs

• Resolution: 16-bit

• Accuracy: ±0.2% FS

• Sampling Rate: 1 kHz per channel

• Supply Voltage: 24 V DC

• Operating Temperature: –20 ℃ to +60 ℃

• Mounting: DIN rail installation

• Degree of Protection: IP20

• Communication Interface: Via backplane or bus to main controller

• Standards: Complies with IEC 61131 and industrial automation standards

• Typical Applications: Process control, industrial automation, DCS/PLC analog expansion

3. Advantages and Features

1. High-Precision Acquisition and Output
   16-bit resolution with ±0.2% FS accuracy ensures precise process control.

2. Multi-Channel Expansion
   8 analog inputs and 8 analog outputs meet complex industrial system requirements.

3. Strong Compatibility
   Seamless integration with ABB DCS and PLC systems, supporting modular expansion.

4. High-Speed Response
   1 kHz per channel sampling rate meets real-time control demands.

5. Easy Installation and Maintenance
   DIN rail mounting and modular design simplify expansion and replacement.

4. Applications

• Industrial process control systems

• Distributed Control Systems (DCS)

• PLC system analog expansion

• Energy management and monitoring

• Industrial automation and production line control

5. Installation and Usage Notes

1. Verify module model and compatibility with the main controller before installation.

2. Observe voltage and current input/output polarity to avoid module damage.

3. Ensure stable 24 V DC supply voltage for reliable operation.

4. Avoid operating the module in high temperature, high humidity, or strong electromagnetic interference environments.

5. Regularly check wiring and module status to ensure reliable data acquisition and output.
