ABB W2E200-HH38-06 Cooling Fan

1. Key Parameters

• Product Model: W2E200-HH38-06
• Order Code Reference: Typically paired with ABB VFD cooling kits (e.g., 3ABD00012987) for procurement consistency
• Product Series: ABB Industrial Axial Cooling Fans for Power Electronics
• Core Function: Provides forced convection cooling for ABB power electronics; dissipates heat from high-power components to maintain safe operating temperatures; prevents thermal throttling or component failure
• Aerodynamic & Performance Specifications:
  • Fan Type: Axial flow fan (forward-curved blades)
  • Dimensions (Diameter × Thickness): 200mm × 60mm (standard 200mm fan form factor for ABB equipment)
  • Airflow Rate: 120 CFM (cubic feet per minute) / 204 m³/h (cubic meters per hour)
  • Static Pressure: 25 Pa (max; sufficient to overcome airflow resistance in ABB VFD enclosures)
  • Air Velocity: 3.2 m/s (at fan outlet)
  • Noise Level: 58 dBA (at 1m distance; compliant with industrial noise standards)
• Electrical Specifications:
  • Power Supply: 230V AC (single-phase; 50Hz~60Hz auto-adaptive)
  • Rated Current: 0.35A (nominal); 0.5A (startup peak)
  • Power Consumption: 75W (max)
  • Speed Control: Fixed speed (1450 RPM at 50Hz; 1750 RPM at 60Hz); optional PWM speed control via ABB temperature sensors (requires compatible ABB controller)
  • Protection Class: IP54 (ingress protection; dust-tight, protected against low-pressure water jets from any direction)
• Mechanical & Structural Specifications:
  • Housing Material: Die-cast aluminum (frame) + glass-fiber reinforced plastic (blades); flame-retardant (UL94 V-0)
  • Bearing Type: Dual ball bearings (for long life; superior to sleeve bearings in industrial environments)
  • Mounting Type: Flange-mounted (4 M5 mounting holes; compatible with ABB VFD enclosure mounting points)
  • Weight: Approximately 850g
  • Connector Type: 3-pin industrial terminal (wired for 230V AC; includes ground pin for safety)
  • LED Status Indicator: 1× green LED (on fan frame); illuminates when fan is powered and running
• Environmental & Durability Ratings:
  • Operating Temperature Range: -20℃~+70℃ (-4℉~158℉); withstands high ambient temperatures in VFD enclosures
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: ≤95% RH (non-condensing, 40℃; suitable for damp industrial settings)
  • Vibration Resistance: 5~500Hz, 1.8g acceleration (IEC 60068-2-6; no blade or bearing damage)
  • Shock Resistance: 30g acceleration (11ms duration, IEC 60068-2-27; maintains structural integrity)
  • Service Life: 50,000 hours (MTBF, mean time between failures) at 40℃ operating temperature (dual ball bearings ensure long lifespan)
• Compliance Standards: IEC 60335-1 (household and similar electrical appliances), EN 61000-6-2 (EMC immunity), UL 507 (fans and blowers), CE, RoHS

2. Key Features

• ABB Equipment Exclusivity: Custom-engineered for ABB ACS series VFDs (e.g., ACS880 150kW~250kW models) and power modules—form factor, airflow rate, and mounting points match ABB’s enclosure design, eliminating compatibility issues (e.g., insufficient airflow, improper fit) common with generic fans.
• IP54 Industrial Protection: Dust-tight and water-resistant design prevents dust accumulation on blades (which reduces airflow) and protects internal components from water splashes—ideal for dusty environments (e.g., cement plants) or damp facilities (e.g., water treatment plants).
• Dual Ball Bearings: Delivers 50,000 hours of MTBF (at 40℃) — 3× longer service life than sleeve bearings—reduces maintenance frequency and downtime in 24/7 industrial operations (e.g., continuous manufacturing lines).
• High Airflow & Static Pressure: 120 CFM airflow and 25 Pa static pressure efficiently dissipate heat from ABB VFD IGBT modules (which generate significant heat during high-load operation); prevents thermal throttling (where VFDs reduce output to avoid overheating), ensuring full power delivery.
• Flame-Retardant Materials: UL94 V-0 flame-retardant housing and blades comply with industrial safety standards—prevents fire spread in case of electrical faults (e.g., fan motor overheating), enhancing equipment safety in high-power environments.
• Global Voltage Compatibility: 230V AC 50/60Hz auto-adaptive power supply supports international deployment—no hardware modifications required for use in Europe (50Hz), North America (60Hz), or Asia (50/60Hz mixed grids).
• Integrated Status Monitoring: Green LED indicator provides visual confirmation of fan operation—technicians can quickly verify fan functionality during maintenance checks without specialized tools (e.g., airflow meters).

3. Application Fields

• ABB ACS Series VFD Cooling: Primary application—thermal management for high-power VFDs:
  • Manufacturing: Cools ACS880 VFDs driving 200kW~250kW conveyor motors in automotive assembly plants; high airflow dissipates heat from IGBTs during peak production loads (e.g., full-speed conveyor operation), preventing VFD shutdowns.
  • Mining: Cools ACS880 VFDs for mine hoist motors; IP54 protection resists dust from ore transport, while dual ball bearings withstand vibration from hoist operation—ensures reliable cooling in underground mining environments.
  • Chemical Processing: Cools ACS580 VFDs for centrifugal pump motors; IP54 water resistance protects against chemical plant washdowns, and high static pressure overcomes airflow resistance from VFD enclosure filters—maintains pump operation during temperature spikes.
• ABB Power Module & Controller Cooling: Supports thermal management for other ABB equipment:
  • Power Generation: Cools ABB power conditioning modules in fossil fuel power plants; 120 CFM airflow dissipates heat from rectifier components, ensuring stable power supply to auxiliary systems (e.g., boiler feedwater pumps).
  • Industrial Automation: Cools ABB AC800PEC controllers in process control panels; compact 200mm form factor fits tight panel spaces, while IP54 protection prevents dust from affecting controller performance.
• Harsh-Environment Thermal Management: Enables reliable cooling in extreme settings:
  • Steel Mills: Cools ABB VFDs for rolling mill motors; high operating temperature range (-20℃~+70℃) withstands hot mill environments (ambient temperatures up to +50℃), while dual ball bearings resist vibration from metal rolling.
  • Food & Beverage Processing: Cools ACS580 VFDs for mixer motors; IP54 protection resists water splashes during facility washdowns (required for food safety), and flame-retardant materials comply with food industry safety standards.

The structure and details of the product：
