ABB UMC22-PAN Universal Motor Controller (Panel Mount)

• 1. Product Overview

  ABB UMC22-PAN Universal Motor Controller is a high-performance, compact panel-mount device designed for low-voltage AC or DC motors, providing start, stop, forward/reverse, speed control, and overload protection.

  The controller integrates advanced electronic protection and status monitoring functions, ensuring reliable, energy-efficient, and safe motor operation.

  UMC22-PAN is suitable for pumps, fans, compressors, and general industrial machinery applications.

  ---

  2. Main Technical Data

  General

  • Product type:
    Universal Motor Controller (UMC)

  • Mounting:
    Panel mount

  • Applicable motor type:
    Three-phase AC / DC motor

  • Control functions:
    Start/stop, forward/reverse, overload protection, overcurrent protection, short-circuit protection

  • Motor power range:
    0.37 kW – 15 kW (AC motor, depends on voltage)

  • Supply voltage:
    200–600 V AC / 24–48 V DC (model dependent)

  • Control signals:
    Compatible with digital I/O and analog input signals

  Protection & Monitoring

  • Overload protection:
    Adjustable thermal relay or electronic overload protection

  • Short-circuit protection:
    Built-in fast fuse or circuit breaker

  • Status indication:
    LED indication for operation, alarm, and fault

  Mechanical & Environment

  • Panel cut-out size:
    72 mm × 72 mm (standard panel cut-out, model dependent)

  • Housing:
    Flame-retardant plastic or metal front panel

  • Operating temperature:
    -20°C to +60°C

  • Protection rating:
    IP54 (front panel)

  Standards & Certification

  • Compliance:
    IEC 60947-4-1 / IEC 60947-1 / EN 60204

  • Operating environment:
    Industrial automation, motor control, and equipment protection

  ---

  3. Key Advantages and Features

  1. Integrated multifunctional control
     Start/stop, forward/reverse, overload, and short-circuit protection in a single unit, saving panel space.

  2. Compact panel-mount design
     Saves control cabinet space; suitable for standard panel cut-outs.

  3. High reliability and protection
     Built-in electronic or thermal protection ensures safe motor operation.

  4. Status monitoring and indication
     LED display shows operation, fault, and alarm information, facilitating maintenance.

  5. Wide voltage compatibility
     Adaptable to various industrial power systems.

  6. Energy-efficient operation
     Optimizes motor start-up and running, improving overall system efficiency.

  ---

  4. Typical Applications

  • Pump, fan, and compressor motor control

  • Industrial machinery motor start and protection

  • HVAC motor control

  • Conveyor and production line motor control

  • Distribution and automation control systems

  • Laboratory and small-scale factory motor control

  ---

  5. Installation and Application Notes

  1. Verify motor and supply compatibility
     Ensure controller rated current and voltage match motor parameters before installation.

  2. Correct wiring
     Connect power, control signals, and motor according to the manual for safety.

  3. Panel mounting compliance
     Maintain panel cut-out size and protection rating; prevent dust or moisture ingress.

  4. Environmental conditions
     Avoid extreme temperature, humidity, or corrosive environments.

  5. Periodic maintenance
     Check indicators, protection functions, and wiring status for long-term reliable operation.

•

The structure and details of the product：

Please make an inquiry for more models
