ABB UGE0221AY4 high-voltage rectifier
Item NO.:
UGE0221AY4Payment:
T/TPrice:
$325Product Origin:
FRANCEColor:
NEWProduct weight:
0.25KGLead Time:
in stockModel: UGE0221AY4
Type: High-Voltage Rectifier Module (UGE Series)
Manufacturer: ABB / IXYS (Littelfuse Group)
The UGE0221AY4 is a single high-voltage rectifier diode module featuring high dielectric strength, strong surge tolerance, and sealed epoxy encapsulation. It is designed for use in high-voltage DC power systems, laser power supplies, electrostatic and testing equipment requiring high insulation reliability.
| Parameter | Specification |
|---|---|
| Model | UGE0221AY4 |
| Type | Single-leg high-voltage rectifier module |
| Repetitive Peak Reverse Voltage (VRRM) | 4800 V |
| Average Rectified Current (Io) | 10.2 A |
| Forward Voltage Drop (Vf, IF=30A, Tj=25°C) | ≈ 4.8 V |
| Surge Current (IFSM, 10ms, Tj=45°C) | 180 A |
| Surge Current (IFSM, 10ms, Tj=150°C) | ≈ 140 A |
| Reverse Power (PRSM, 10µs) | 3.4 kW |
| Reverse Leakage Current (IR, Tj=150°C) | < 2 mA |
| Internal Resistance (rT) | ≈ 90 mΩ |
| Threshold Voltage (VT0) | ≈ 2.55 V |
| Junction Temperature (Tj) | –40°C to +150°C |
| Storage Temperature (Tstg) | –40°C to +150°C |
| Packaging | Epoxy sealed, oil-compatible |
| Dimensions | Ø55 mm × 23 mm |
| Mounting | M8 stud terminals (anode/cathode) |
| Weight | ≈ 120 g |
| Standard Compliance | IEC 60747-2 |
High Voltage Capability – withstands up to 4.8 kV reverse voltage.
High Average Current Rating – supports up to 10.2 A continuous operation.
Excellent Surge Capability – 180 A surge current (10 ms pulse).
Sealed Epoxy Structure – moisture-resistant, suitable for oil immersion.
Wide Thermal Range – reliable from –40°C to +150°C.
Flexible Connection – can be used in series or parallel configurations.
High Reliability – robust mechanical and electrical performance for long service life.
X-ray and medical imaging equipment
Electrostatic precipitators and corona discharge systems
High-voltage test benches and cable withstand testers
Laser and pulsed laser power supplies
Vacuum tube and ion generator systems
Industrial high-voltage DC power supplies
Electron beam systems and laboratory HV converters
Thermal Management: Use proper heatsinks or oil cooling to maintain safe junction temperature.
Voltage Margin: Design with 10–20% safety margin below 4800 V.
Surge Protection: Include snubber networks or fast fuses to suppress transients.
Series/Parallel Matching: Ensure balanced voltage or current distribution.
Insulation: Maintain sufficient creepage and clearance distances.
Operation Life: Avoid continuous operation near rated limits.
Periodic Inspection: Monitor leakage current, temperature, and forward voltage drop regularly.
The structure and details of the product：
--------------占位---------------
Please make an inquiry for more models
