ABB TZIDC-200 Electronically Configurable Positioner

1. Product Overview

The ABB TZIDC‑200 Electronically Configurable Positioner is an industrial electronic valve position controller designed to accurately control the position of valve actuators.
It integrates electronic control, feedback sensing, intelligent diagnostics, and configurable parameters to deliver high‑precision positioning for linear or rotary actuators. The TZIDC‑200 receives control signals and adjusts actuator travel to achieve precise valve modulation, enhancing process stability in automated systems.

2. Technical Specifications

• Model: TZIDC‑200

• Type: Electronically Configurable Positioner

• Brand: ABB

• Applicable Actuators: Pneumatic / Electric valve actuators

• Power Supply: 24 V DC ± 10%

• Control Input Signal: 4–20 mA / 0(1)–5 V / 0(2)–10 V

• Feedback Output: 4–20 mA or 0–10 V analog feedback

• Control Mode: Proportional positioning / valve position control

• Operating Medium: Compressed air (for pneumatic actuators)

• Response Time: ≤ 1 second (typical)

• Positioning Accuracy: ± 0.5% of full scale

• Protection Class: IP65 (suitable for industrial environments)

• Operating Temperature: ‑20 ℃ to +70 ℃

• Storage Temperature: ‑40 ℃ to +85 ℃

• Humidity: 5%–95% RH (non‑condensing)

• Mounting: Direct mount on actuator top or bracket

• Material: Industrial‑grade plastic and metal components

• Dimensions (approx.): 120 mm × 90 mm × 75 mm

• Weight (approx.): 0.8 kg

3. Key Advantages & Features

1. High‑Precision Position Control
   High resolution feedback and digital PID control enable positioning accuracy of ±0.5%.

2. Flexible I/O Compatibility
   Supports multiple analog input/output signal formats for seamless integration with PLC, DCS or controllers.

3. Configurable Parameters
   Control response, dead‑band compensation, and gain settings can be configured to suit application needs.

4. Fast Response & Stability
   Quick control response with minimal oscillation enhances system dynamics and stability.

5. Industrial‑Grade Reliability
   IP65 enclosure and wide temperature tolerance ensure durability in harsh field environments.

6. Intelligent Diagnostics & Feedback
   Provides actuator feedback, status indication, and fault alarms for remote monitoring and maintenance.

4. Typical Applications

• Process control in chemical and petrochemical plants

• Power generation and energy automation systems

• Metallurgical, pulp & paper, and wastewater valve control

• HVAC valve modulation and building automation

• Industrial fluid control and automated production lines

• Gas, steam, and liquid flow regulation systems

5. Installation & Usage Notes

1. Power & Signal Compatibility
   Verify power supply and control signal types match system requirements before installation.

2. Proper Mounting & Alignment
   Ensure secure mechanical linkage to the actuator and proper alignment to avoid travel deviations.

3. Wiring Practices
   Use shielded cable and good grounding practices to minimize electrical noise on signals.

4. Environmental Considerations
   Despite IP65 protection, avoid prolonged exposure to corrosive chemicals, high temperatures, or standing water.

5. Configuration & Calibration
   Set response parameters and perform travel limit and dead‑zone compensation during commissioning.

6. Maintenance & Inspection
   Periodically inspect air quality (for pneumatic systems), cable connections, and feedback signal stability.
