ABB TU839 (3BSE046966R1) Expansion Module

1. Key Parameters

• Product Model: TU839
• Order Code: 3BSE046966R1
• Product Series: ABB TU Series S800 I/O Expansion Modules (I/O Channel Extension, Remote Rack Connectivity)
• Core Function: Expands ABB S800 I/O system capacity with additional signal channels; enables remote S800 rack connectivity via fiber/copper links; provides signal isolation and conditioning; supports hot-swapping for maintenance; ensures compatibility with ABB automation ecosystems
• Electrical & I/O Specifications:

  Parameter	Details	Performance Metrics
  I/O Expansion Capacity	- Supported I/O Types: Analog Input (AI), Analog Output (AO), Digital Input (DI), Digital Output (DO) - Maximum I/O Channels: Up to 64 channels (via 4x S800 I/O module slots) - Signal Compatibility: 4~20mA (AI/AO), 24V DC (DI/DO), 110V AC (DI, optional) - Signal Isolation: 2.5kV AC (channel-to-channel, 1min)	Enables flexible scaling of I/O capacity—adds 64 channels to existing S800 racks, avoiding the need for full rack replacement
  Remote Connectivity	- Communication Interface: ABB PRONETA (Process Network for Ethernet-based Automation) - Link Type: Fiber optic (multimode, 50/125μm) or copper Ethernet (100Base-TX) - Maximum Distance: 2km (fiber optic); 100m (copper Ethernet) - Data Transfer Rate: 100Mbps (full-duplex, real-time)	Supports remote I/O deployment (e.g., process skids 2km from main control cabinet), reducing wiring costs by 70% vs. direct cabling
  Signal Conditioning	- Input Filtering: 50/60Hz notch filter (AI channels); debounce (1ms~100ms, DI channels) - Output Regulation: ±0.1% accuracy (AO channels, 4~20mA) - Noise Rejection: ≥80dB (CMRR, AI channels) - Overvoltage Protection: ±15kV ESD (contact, IEC 61000-4-2)	Ensures signal integrity in noisy industrial environments (e.g., near motor drives), reducing AI measurement errors to <0.1%
  Safety & Compliance	- Hot-Swap Support: Yes (I/O modules and communication cards, per IEC 61326-3-2) - Safety Certification: IEC 61010-1, UL 61010-1, CSA C22.2 No. 61010-1 - EMI/EMC Compliance: EN 61000-6-2 (industrial immunity); EN 61000-6-4 (emission) - Flame Class: UL 94 V0 (housing material)	Hot-swapping minimizes downtime during module replacement; global certifications ensure compliance in multi-region projects

• Mechanical Specifications:
  • Dimensions: 100mm (W) × 220mm (L) × 80mm (H) (compatible with S800 rack enclosures)
  • Mounting Type: Direct snap-on to ABB S800 rack backplanes; optional wall mount (with adapter)
  • Housing Material: Glass-fiber reinforced polyamide (PA66+GF, impact-resistant, RAL 7035)
  • Weight: Approximately 550g (without I/O modules)
  • Cooling Method: Convection cooling (passive, no fans)
• Environmental Ratings:
  • Operating Temperature Range: -25℃~+70℃ (-13℉~158℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
  • Altitude Rating: Up to 2000m (no derating required)
  • Vibration Resistance: 10~500Hz, 1.5g acceleration (IEC 60068-2-6; no module loosening)
  • Shock Resistance: 30g (11ms half-sine, IEC 60068-2-27; no functional failure)
• Compliance Standards: CE, RoHS, ABB S800 I/O Compatibility Standard V6.0+, IEC 61326-3-2 (industrial automation equipment)

2. Key Features

• 64-Channel I/O Expansion: Supports up to 64 analog/digital channels via 4 S800 I/O module slots—enables cost-effective scaling of existing S800 systems (e.g., adding 32 AI channels for temperature sensors in a chemical plant) without replacing the main rack.
• Dual Remote Link Options: Fiber optic (2km) or copper Ethernet (100m) connectivity via PRONETA—ideal for remote process skids, offshore platforms, or large factories where main control cabinets are distant from field devices, reducing wiring complexity and cost.
• 2.5kV Channel Isolation: Prevents ground loops and cross-talk between I/O channels—critical for sensitive measurements (e.g., 4~20mA pressure signals in a refinery) and protects modules from voltage spikes in distant field circuits.
• Hot-Swap Capability: Allows replacement of I/O modules and communication cards without powering down the system—reduces unplanned downtime by 90% during maintenance (e.g., replacing a faulty DI module in a 24/7 manufacturing line).
• Integrated Signal Conditioning: 50/60Hz notch filters, debounce settings, and high CMRR—ensures clean, accurate signals in noisy industrial environments (e.g., near ACS800 motor drives), eliminating false DI triggers and AI measurement errors.
• Compact S800 Rack Compatibility: 100mm-wide form factor snaps directly to S800 rack backplanes—saves 40% space compared to standalone expansion racks, enabling dense installation alongside existing I/O modules (e.g., AI893, DI825) and termination units (e.g., TU860).
• Wide Environmental Tolerance: -25℃~+70℃ operating range and 1.5g vibration resistance—operates reliably in extreme conditions: cold storage (food processing), high-temperature process zones (steel mills), and humid offshore platforms (with IP-rated enclosures).

3. Application Fields

• ABB S800 I/O System Scaling: Primary application—expanding existing ABB control systems:
  • Chemical Plant 800xA DCS Expansion: Adds 64 AI channels (4~20mA) for reactor temperature/pressure sensors to an existing S800 rack; 2.5kV isolation prevents ground loops between the main rack and new process skid, ensuring accurate process control.
  • AC800M PLC I/O Extension: Extends a factory AC800M system with 32 DO channels (24V DC) for valve control; hot-swap capability allows replacement of a faulty DO module during production shifts, avoiding line shutdowns.
• Remote I/O Deployment: Connecting distant field devices to main control cabinets:
  • Oil Refinery Remote Process Skids: Links 64 DI/DO channels (valve status, pump controls) on a remote skid to the main 800xA DCS via 2km fiber optic link; fiber connectivity eliminates EMI interference from refinery power systems and reduces wiring costs by 70%.
  • Water Treatment Plant Pump Stations: Connects 32 AI channels (flow meters, level sensors) in a remote pump station to the central SCADA system via copper Ethernet; integrated signal conditioning filters out noise from pump motors, ensuring reliable water flow monitoring.
• Harsh Environment I/O Expansion: Reliable operation in extreme conditions:
  • Mining Underground Control Systems: Expands S800 I/O with 64 DI channels (conveyor safety interlocks) in underground tunnels; wide temperature range (-25℃~+70℃) handles cold underground environments, while vibration resistance (1.5g) withstands machinery motion.
  • Food Processing Line Hygienic Zones: Adds 32 AO channels (valve position control) to a S800 system in a washdown area; PA66+GF housing resists caustic cleaners, and passive cooling avoids dust ingestion, complying with FDA hygienic standards.
• Large-Scale Manufacturing Automation: Supporting high-channel-count applications:
  • Automotive Assembly Line I/O Expansion: Extends an AC800M system with 64 mixed DI/AI channels (robot position sensors, weld temperature monitors); PRONETA copper Ethernet (100m) connects the expansion module to the main rack, simplifying wiring in a large factory floor.
  • Electronics Semiconductor Fab I/O Scaling: Adds 32 AI channels (wafer temperature, vacuum pressure) to a cleanroom S800 rack; signal conditioning eliminates noise from high-frequency equipment, ensuring precise control of semiconductor manufacturing processes.

4. Precautions

• I/O Module Compatibility (Critical): Use only ABB S800-series I/O modules (e.g., AI893, DI825, AO890) with the TU839—third-party or non-S800 modules lack electrical compatibility and may damage the expansion module or main rack; verify module firmware ≥V6.0 for full functionality.
• Installation & Wiring Safety:
  • Remote Link Wiring: For fiber optic links, use only multimode 50/125μm fiber (per ABB specifications)—incorrect fiber type (e.g., single-mode) reduces distance and causes data loss; for copper Ethernet, use shielded Cat5e/Cat6 cable to minimize EMI.
  • Isolation Integrity: Maintain 2.5kV creepage/clearance distances (≥6mm) between I/O terminals and other components—reduced distances compromise isolation, leading to signal interference or module damage.
  • Polarity & Channel Mapping: Follow ABB Control Builder M guidelines for I/O channel mapping—incorrect mapping (e.g., assigning a DI channel to an AI module) causes communication errors; verify mapping with the 800xA DCS before commissioning.
• Operation & Maintenance:
  • Hot-Swap Procedure: Follow ABB’s hot-swap protocol (deactivate the module in 800xA before removal) — improper hot-swapping may corrupt I/O data or damage the backplane; use only ABB-approved tools for module removal.
  • 定期检查: Inspect quarterly for:
    • Loose backplane connections (common after vibration)
    • Damaged fiber/copper connectors (from mechanical stress)
    • Overheating (check for hotspots via thermal imaging)
      Clean fiber connectors with lint-free wipes and isopropyl alcohol to maintain signal integrity.
  • Remote Link Monitoring: Monitor PRONETA link status via 800xA diagnostics—link errors (e.g., high packet loss) indicate cable damage or EMI interference; resolve immediately to avoid I/O data loss.
• Environmental Limitations:
  • Temperature Extremes: Do not operate above +70℃ or below -25℃—high temperatures degrade backplane components, while extreme cold increases signal latency; use cabinet heaters/coolers in extreme zones to maintain -25℃~+70℃.
  • Condensing Humidity: Avoid operation in condensing humidity (>95% RH, 40℃)—condensation causes internal short circuits; use dehumidifiers in humid environments (e.g., offshore platforms, water treatment plants).
• Replacement & Spare Parts:
  • Genuine ABB Components: Use only genuine ABB TU839 (3BSE046966R1) modules and S800 I/O modules—non-genuine alternatives lack PRONETA compatibility and isolation standards, leading to system failures and potential damage to the main S800 rack.
  • Spare Inventory: Maintain 1~2 spare TU839 modules per 5 expansion points—expansion module failures disconnect 64 I/O channels; spares reduce downtime from 2+ weeks (delivery) to <1 hour for mission-critical systems (e.g., refinery process control)
