ABB TU836V1 3BSE013237R1 Expansion Module Terminal Unit

Product Overview

The ABB TU836V1 is an expansion module terminal unit designed for industrial automation systems to interface and manage signals between additional I/O modules and the main control system. The unit provides reliable signal distribution, terminal connections, and modular interfaces, supporting flexible system expansion, simplified wiring, and maintenance. TU836V1 features a compact modular design suitable for installation in control cabinets and is widely used in distributed control systems (DCS), PLC systems, and industrial automation environments.

Technical Specifications (Typical)

• Model: TU836V1 (3BSE013237R1)

• Type: Expansion Module Terminal Unit

• I/O Interfaces: Supports standard analog and digital I/O modules

• Wiring Method: Terminal connection

• Supply Voltage: 24 V DC (for module power)

• Maximum Power Consumption: ≤ 5 W

• Operating Temperature: 0°C – +55°C

• Mounting: DIN rail or panel mount

• Status Indicators: None (depends on connected modules)

• Protection Rating: IP20

• Dimensions: approx. 160 mm × 80 mm × 60 mm

• Weight: approx. 0.6 kg

Features and Advantages

1. Modular Expansion Design: Easily add additional I/O modules to expand system capacity.

2. High Reliability: Ensures stable signal transmission for expansion modules.

3. Simplified Wiring: Standardized terminal interface reduces wiring errors and commissioning time.

4. Compact Design: Saves control cabinet space and facilitates installation and maintenance.

5. Strong System Compatibility: Compatible with ABB DCS, PLC, and distributed I/O systems.

6. Industrial-Grade Durability: EMI-resistant design suitable for harsh industrial environments.

Application Areas

• Expansion of distributed control systems (DCS) and PLC systems

• Industrial control cabinets and additional I/O module interfaces

• Process control in power, chemical, petrochemical, and metallurgical industries

• Smart factories and Industrial IoT (IIoT) applications

• Automated production line I/O signal integration and expansion

Precautions

1. Disconnect power before installation to ensure safety.

2. Follow terminal labeling and wiring diagrams to avoid short circuits or signal errors.

3. Ensure a ventilated and dry environment; avoid high temperature, humidity, and corrosive gases.

4. Expansion module termination units should be properly matched with the main module and other I/O modules.

5. Periodically check wiring and module installation to ensure reliable system operation.

6. Installation, commissioning, and maintenance should be performed by qualified personnel.
