ABB TTH300 E1 Head-mounted temperature sensor

Product Information: ABB TTH300 E1 Head-mounted Temperature Sensor

Detailed Specifications:

• Model: TTH300 E1

• Type: Head-mounted Temperature Sensor

• Measurement Range: -50°C to +200°C

• Accuracy: ±0.5°C (within -20°C to +80°C range)

• Output Signal: 4-20 mA or 0-10 V (optional)

• Sensor Type: Thermocouple or RTD (depending on requirement)

• Response Time: ≤ 10 seconds (typical)

• Rated Voltage: 24 V DC

• Current Consumption: < 20 mA

• Ingress Protection: IP67 (dustproof and waterproof)

• Operating Temperature Range: -40°C to +80°C (sensor housing)

• Storage Temperature: -40°C to +85°C

• Material: Stainless steel housing, corrosion-resistant

• Mounting Type: Head-mounted, suitable for contact temperature measurement

• Connection Type: M12 connector (or as per customer requirement)

• Dimensions: 100 mm x 50 mm

• Weight: 0.25 kg

• Certifications: CE, Ex (ATEX Explosion-proof certification), IECEx

Product Advantages and Features:

1. High-Precision Temperature Measurement: The ABB TTH300 E1 head-mounted temperature sensor uses advanced measurement technology to provide highly accurate temperature readings, ensuring data reliability and precision.

2. Durability: With its stainless steel housing, the sensor is highly corrosion and abrasion-resistant, suitable for use in harsh environments. It has an IP67 ingress protection rating, ensuring stable operation in damp, dusty, and complex environments.

3. Multiple Output Signals: Offers selectable output signals (4-20 mA or 0-10 V), making it compatible with various control systems and suitable for a wide range of industrial automation applications.

4. Fast Response: The sensor has a quick response time, providing rapid temperature changes detection, making it suitable for real-time temperature monitoring applications.

5. Easy Installation: The head-mounted design simplifies installation, making it easy to integrate into various machinery and systems for temperature monitoring.

6. Wide Applications: Ideal for precise temperature monitoring in industrial sectors such as heating systems, cooling systems, chemical processes, food processing, and pharmaceutical industries.

7. Explosion-Proof Certification: With Ex (ATEX Explosion-proof) and IECEx certifications, it is safe for use in hazardous environments.

Applications:

• Industrial Automation: Provides precise temperature data for various industrial control systems, ensuring equipment operates within optimal temperature ranges.

• Heating and Cooling Systems: Widely used for temperature monitoring in heating and cooling equipment, helping to optimize performance and prevent overheating or inadequate cooling.

• Chemical and Pharmaceutical Industries: Used for temperature monitoring in reactors, evaporators, dryers, and other equipment, ensuring process control accuracy and safety.

• Food Processing and Cold Chain Management: Monitors temperature during food processing and cold chain transportation, ensuring product quality and safety.

• Hazardous Environments: Suitable for temperature measurement in hazardous areas such as oil, gas, and chemical processing, with explosion-proof capabilities ensuring operational safety.

Precautions:

1. Proper Installation: Ensure the sensor has good contact with the measured object to ensure accurate temperature measurements.

2. Regular Calibration: Periodically calibrate the sensor to maintain long-term accuracy in measurements.

3. Avoid High-Temperature Shock: Prevent exposure to temperatures exceeding the sensor’s maximum measurement range to avoid damage.

4. Environmental Suitability: Avoid using the sensor in extreme environments, especially those with high humidity or corrosive gases.

5. Explosion-Proof Requirements: For use in explosive areas, ensure installation complies with relevant explosion-proof standards to ensure safety.

The structure and details of the product：
