ABB TS3N125TW Molded Case Circuit Breaker

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Description

The ABB TS3N125TW Molded Case Circuit Breaker (MCCB) is an industrial-grade low-voltage circuit protection device widely used in power distribution systems and industrial control panels. It provides overload, short-circuit, and under-voltage protection. The TS3N125TW features high breaking capacity, precise protection characteristics, and high reliability, ensuring safety for equipment and personnel.

2. Technical Specifications

• Model: TS3N125TW

• Type: Molded Case Circuit Breaker (MCCB)

• Rated Current: 125 A

• Poles: 3 poles

• Rated Voltage: AC 400 V / DC 250 V

• Short-Circuit Breaking Capacity: 25 kA (IEC/EN standard)

• Breaking Characteristics: Thermal-magnetic protection

• Trip Curve Options: B, C, D type selectable

• Mounting: DIN rail or bolt mounting

• Mechanical Life: ≥ 10,000 operations

• Electrical Life: ≥ 4,000 operations

• Operating Temperature: -5 ℃ to +40 ℃

• Protection Class: IP20

• Standards Compliance: IEC 60947-2, CE, UL

3. Advantages and Key Features

• High reliability with precise thermal-magnetic trip design for accurate overload and short-circuit protection.

• High breaking capacity up to 25 kA, suitable for industrial and commercial distribution systems.

• Selectable trip curves (B, C, D) to match various load characteristics and protection requirements.

• Long lifespan with mechanical life ≥ 10,000 operations and electrical life ≥ 4,000 operations.

• Easy installation and maintenance with DIN rail or bolt mounting, compact design for convenient service.

4. Typical Applications

• Industrial low-voltage distribution systems

• Power distribution and control panels

• Motor and electrical equipment protection

• HVAC systems and large building electrical systems

• Chemical, pharmaceutical, food, and machinery production lines

5. Precautions

• Disconnect power before installation or maintenance to prevent electric shock and equipment damage.

• Ensure rated current and voltage match system requirements to avoid nuisance trips or equipment damage.

• Regularly inspect breaker status and terminal connections for safe and reliable operation.

• Avoid exposure to high humidity, dust, or corrosive environments.

• Do not disassemble or modify the breaker to maintain performance and safety.

The structure and details of the product：
