ABB TMAX T5L 400 Molded Case Circuit Breaker

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB TMAX T5L 400 Molded Case Circuit Breaker is a high-performance, compact low-voltage protection device designed for medium- and high-capacity power distribution systems. It offers excellent short-circuit and overload protection, ensuring stable operation of electrical networks. With a robust structure and flexible installation options, it is widely applied in industrial, commercial, and utility power systems.

2. Technical Specifications

1. Electrical Ratings

• Rated current (In): 400 A

• Rated insulation voltage (Ui): 750 V AC

• Rated operational voltage (Ue): 690 V AC

• Rated impulse withstand voltage (Uimp): 8 kV

• Number of poles: 3P or 4P

• Protection type: L type (long-time, short-time, instantaneous protection)

2. Breaking Capacity

• Ultimate short-circuit breaking capacity (Icu):

  • 36 kA (400 V AC)

• Service short-circuit breaking capacity (Ics):

  • 0.6 × Icu

3. Mechanical & Structural Data

• Operation: Manual or motorized (optional)

• Mounting: Fixed or withdrawable

• Mechanical endurance: Approx. 20,000 operations

• Protection class: IP40 (panel-mounted)

4. Available Accessories

• Undervoltage release

• Shunt trip

• Auxiliary/Alarm contacts

• Motor operator

• Remote control module

3. Advantages & Features

• High breaking capacity ensuring safe interruption of fault currents.

• Compact design suitable for various switchboards and panels.

• Modular accessories allow flexible protection and automation options.

• Excellent selectivity with upstream and downstream devices.

• High reliability and long mechanical life for harsh industrial environments.

• Easy maintenance and fast installation reduce downtime.

4. Application Fields

• Industrial power distribution systems

• Power generation and substations

• Commercial building switchboards

• Data centers and server rooms

• HVAC and building engineering systems

• Public infrastructure (hospitals, airports, rail systems)

5. Precautions

• Ensure the breaker rating matches the actual load before installation.

• Tighten all terminals securely to avoid overheating from poor connections.

• Avoid installation in humid or corrosive environments without proper enclosure.

• Regularly inspect the trip unit and mechanical components.

• Use only ABB-approved accessories for communication or remote-control functions.
