ABB TC505 1SBP260150R1001 Control Panel

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB TC505 1SBP260150R1001 Control Panel is a centralized control and monitoring interface for ABB industrial automation systems. It provides a clear layout with buttons, indicator lights, and display functions for real-time control and status monitoring of motors, pumps, fans, and other industrial equipment. The TC505 panel is suitable for industrial process control systems, electromechanical equipment, and building automation, offering operators an intuitive and reliable user interface.

2. Technical Specifications

• Model: TC505 1SBP260150R1001

• Product Type: Control Panel

• Panel Dimensions: Approx. 500 × 300 × 150 mm (may vary by configuration)

• Display Type: LED indicators / Digital display

• Control Functions: Start, Stop, Reset, Emergency Stop, Function Switching

• Input Signals: From sensors, digital and analog interfaces

• Output Signals: Controls contactors, relays, or drives

• Supply Voltage: AC 230 V / DC 24 V (depending on configuration)

• Operating Temperature: –10 ℃ to +55 ℃

• Mounting: Panel / Frame mounting

• Degree of Protection: IP54 (dust and water resistant)

• Standards: IEC 60204, CE, UL

• Typical Applications: Industrial motor control, pumps, fans, HVAC systems, and automated production lines

3. Advantages and Features

1. Intuitive User Interface
   Buttons, indicators, and displays facilitate on-site operation and status monitoring.

2. Multi-Functional Control
   Supports start, stop, reset, emergency stop, and function switching for flexible operation.

3. High Reliability
   Industrial-grade design ensures stable long-term operation in high temperature, dust, and humidity environments.

4. Modular Installation
   Easily integrates with motors, pumps, fans, and automation equipment for system expansion.

5. Safety Protection
   IP54 protection meets industrial safety standards, ensuring operator safety.

4. Applications

• Industrial motor control and automation systems

• Pump and fan control systems

• HVAC systems

• Factory automation production lines

• Building automation and energy management

5. Installation and Usage Notes

1. Verify panel model compatibility with the system before installation.

2. Wiring and installation should be performed by qualified personnel; ensure proper grounding and safety.

3. Install the panel in a dry, well-ventilated environment, avoiding direct sunlight.

4. Regularly inspect indicator lights, buttons, and wiring to ensure reliable long-term operation.

5. Avoid using directly in high-humidity, dusty, or corrosive environments; provide protection if necessary.
