ABB TB84EC Electrode Conductivity Analyzer Emitter

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB TB84EC Electrode Conductivity Analyzer Emitter is a high-precision industrial analysis module designed for measuring the conductivity of liquids. It is intended for online industrial process control and works with the ABB TB84 series conductivity analyzers, providing accurate real-time monitoring of water, chemical solutions, and industrial fluids. Suitable for power, chemical, pharmaceutical, paper, and water treatment industries.

2. Technical Specifications

Electrical Specifications

• Model: TB84EC

• Type: Electrode Conductivity Analyzer Emitter

• Supply Voltage: 24 V DC / 100–240 V AC (optional)

• Output Signal: 4–20 mA / HART communication protocol

• Measurement Range: 0–2000 µS/cm (adjustable per electrode type)

• Accuracy: ±1% FS

• Response Time: ≤ 2 seconds

• Temperature Compensation: Automatic Temperature Compensation (ATC)

• Protection Features: Overload, short-circuit, and reverse polarity protection

Environmental & Installation

• Operating Temperature: –20°C … +60°C

• Storage Temperature: –40°C … +70°C

• Protection Degree: IP65

• Mounting: Panel or wall-mounted installation

• Dimensions (approx.): 200 mm × 150 mm × 100 mm

• Weight (approx.): 1.8 kg

3. Advantages & Key Features

1. High-precision measurement — Accurate liquid conductivity monitoring with fast, stable response.

2. Strong compatibility — Seamlessly integrates with ABB TB84 sensors and analysis systems.

3. Real-time monitoring — 4–20 mA output and HART communication support automated processes.

4. Automatic temperature compensation — Provides precise temperature correction for reliable readings.

5. Industrial-grade durability — IP65 protection, suitable for various industrial environments.

6. Easy installation & maintenance — Panel or wall mounting simplifies deployment and servicing.

4. Application Areas

• Industrial water treatment and boiler water monitoring

• Chemical and pharmaceutical solution concentration control

• Wastewater treatment and reuse monitoring

• Paper and textile industry liquid process monitoring

• Power plant cooling and circulation water management

• Food and beverage production process liquid control

5. Precautions

1. Ensure supply voltage and output signals match system requirements before installation.

2. Verify sensor compatibility with the emitter to ensure measurement accuracy.

3. Avoid installation in areas with strong vibration, electromagnetic interference, or high humidity.

4. Regularly clean the sensor electrodes to maintain accuracy.

5. Disconnect power before disassembly or maintenance to prevent electric shock or damage.

6. Follow manufacturer-recommended calibration intervals for long-term stable operation.

The structure and details of the product：
