ABB TB811 (3BSE008568R1) Module Bus Optical Port

1. Key Parameters

• Product Model: TB811
• Order Code: 3BSE008568R1
• Product Series: ABB TB Series Module Bus Optical Ports (Fiber Optic Bus Connectivity, EMI-Immune Communication)
• Core Function: Converts electrical module bus signals to optical signals (and reverse) for ABB automation systems; enables long-distance, noise-free bus communication; provides electrical isolation between bus segments; supports ABB PRONET/Ethernet-based bus protocols; integrates with S800 I/O racks
• Optical & Bus Specifications:

  Parameter	Details	Performance Metrics
  Optical Transceiver Characteristics	- Type: Multimode fiber (MMF) transceiver - Wavelength: 850nm (VCSEL laser, for short/medium distance) - Optical Power Output: -10dBm ~ -3dBm (transmit) - Receiver Sensitivity: -24dBm (minimum, for 10^-12 BER) - Fiber Compatibility: 50/125μm or 62.5/125μm multimode fiber	Ensures reliable data transmission over standard multimode fiber, compatible with most industrial fiber infrastructure
  Bus Protocol & Data Rate	- Supported Buses: ABB PRONET, Ethernet (100Base-FX), PROFIBUS DP (via optical conversion) - Data Transfer Rate: Up to 100Mbps (full-duplex, for PRONET/Ethernet) - Bus Latency: <10μs (signal conversion delay) - Maximum Transmission Distance: 2km (50/125μm MMF); 1km (62.5/125μm MMF)	Near-zero latency ensures real-time communication for time-sensitive control loops (e.g., 100ms process updates), avoiding system lag
  Electrical Isolation & EMI Protection	- Electrical Isolation: 5kV AC (input to optical output, 1min, IEC 60950-1) - EMI Attenuation: ≥100dB (at 10MHz~1GHz) - Common-Mode Rejection: N/A (optical signal, immune to common-mode noise) - Surge Immunity: ±2kV (contact, IEC 61000-4-2)	Eliminates electrical noise interference from industrial equipment (e.g., motor drives, high-voltage lines) and prevents ground loops between bus segments
  Connection & Interface	- Optical Port: 2×SC/ST connectors (duplex, for transmit/receive) - Electrical Bus Interface: ABB proprietary S800 module bus connector (gold-plated) - Power Requirements: 24V DC ±10% (from S800 rack); 1.5W (typical) - Status Indicators: 2×LEDs (optical link: green = active, red = fault; power: green = on)	Duplex optical connectors enable full-duplex communication; LED indicators provide at-a-glance diagnostics for link health

• Mechanical Specifications:
  • Dimensions: 75mm (W) × 100mm (L) × 30mm (H) (S800 rack-mount form factor)
  • Mounting Type: Direct snap-on to ABB S800 I/O rack backplanes; compatible with standard S800 module slots
  • Housing Material: Glass-fiber reinforced polyamide (PA66+GF, flame-retardant, UL 94 V0)
  • Weight: Approximately 180g
  • IP Rating: IP20 (finger protection, IEC 60529)
• Environmental Ratings:
  • Operating Temperature Range: -25℃~+70℃ (-13℉~158℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
  • Vibration Resistance: 10~500Hz, 1.5g acceleration (IEC 60068-2-6; no optical alignment loss)
  • Shock Resistance: 20g (11ms half-sine, IEC 60068-2-27; no transceiver damage)
• Compliance Standards: CE, RoHS, ABB S800 I/O Compatibility Standard V6.0+, IEC 61326-3-2 (industrial automation), EN 61000-6-2 (EMC immunity)

2. Key Features

• EMI-Immune Optical Communication: Converts electrical bus signals to optical signals, providing ≥100dB EMI attenuation—eliminates interference from high-noise industrial equipment (e.g., ACS800 motor drives, high-voltage transformers), ensuring 99.999% bus communication availability.
• Long-Distance Transmission (Up to 2km): Supports 2km transmission over 50/125μm multimode fiber—enables remote deployment of S800 I/O racks (e.g., 2km from the main 800xA DCS cabinet in an oil refinery), reducing copper wiring costs by 80% vs. traditional bus cables.
• 5kV Electrical Isolation: Provides 5kV AC isolation between electrical bus segments—prevents ground loops (a major cause of bus failures in large facilities) and protects modules from voltage spikes (e.g., lightning-induced transients in outdoor applications).
• Plug-and-Play S800 Compatibility: Snaps directly into ABB S800 I/O rack slots and integrates with existing bus protocols (PRONET, Ethernet)—requires no custom firmware or adapters, reducing commissioning time by 40% for distributed control systems.
• Dual LED Status Monitoring: Separate LEDs for optical link health (green/red) and power (green)—enables quick troubleshooting (e.g., a red link LED flags a broken fiber or mismatched transceiver), reducing mean time to repair (MTTR) by 60%.
• Rugged Industrial Design: PA66+GF housing (UL 94 V0) and 1.5g vibration resistance—maintains optical alignment and signal integrity in harsh environments: high-temperature process zones (steel mills), humid offshore platforms, and dusty mining control rooms.
• Low Power Consumption (1.5W): Draws minimal power from the S800 rack—enables deployment in power-constrained remote segments (e.g., solar-powered oil well monitoring skids) without requiring external power supplies.

3. Application Fields

• High-Noise Industrial Environments: EMI-immune communication near heavy machinery:
  • Steel Mill Rolling Line Controls: Connects S800 I/O racks near rolling mill motors (high EMI) to the main 800xA DCS via 1km fiber—optical signals eliminate noise interference from motor drives, ensuring accurate control of roll speed and temperature.
  • Automotive Factory Robot Cells: Links S800 DI/DO modules in robot cells (high electrical noise) to AC800M PLCs via 500m fiber—prevents false sensor triggers from robot motor EMI, maintaining consistent assembly line performance.
• Long-Distance Distributed I/O: Connecting remote process segments to main control cabinets:
  • Oil Refinery Remote Process Skids: Links a S800 I/O rack on a 2km-distant crude oil skid to the central 800xA DCS—fiber transmission avoids copper wiring costs and signal degradation, ensuring reliable monitoring of pressure and flow sensors.
  • Water Treatment Plant Pipeline Monitoring: Connects S800 AI modules (flow meters, pH sensors) along a 1.5km pipeline to the SCADA system—5kV isolation prevents ground loops between pipeline segments and the main plant, complying with water industry safety standards.
• Harsh & Hazardous Environments: Reliable communication in extreme conditions:
  • Mining Underground Control Systems: Extends S800 bus communication to underground I/O racks via 1km fiber—wide temperature range (-25℃~+70℃) handles cold underground environments, while EMI immunity avoids interference from mining equipment.
  • Chemical Plant Explosion-Proof Zones: Integrates with ATEX-certified fiber enclosures to connect S800 I/O modules in Zone 2 hazardous areas to the main DCS—optical signals eliminate spark risks (unlike copper), complying with ATEX 94/9/EC standards.
• Critical Infrastructure & Energy Sector: Secure, isolated communication:
  • Nuclear Power Plant Auxiliary Systems: Connects safety-related S800 I/O racks to the main control system via fiber—5kV isolation prevents cross-contamination of safety and non-safety circuits, complying with IEC 61513 nuclear safety standards.
  • Solar Farm Inverter Networks: Links S800 I/O modules in outdoor inverter enclosures (1km from the central SCADA) via fiber—EMI immunity avoids interference from inverter power electronics, ensuring accurate energy production monitoring.

4. Precautions

• Fiber Type & Distance Compatibility (Critical): Use only 50/125μm or 62.5/125μm multimode fiber—single-mode fiber (SMF) is incompatible with the 850nm transceiver and will cause signal loss; do not exceed 2km (50/125μm) or 1km (62.5/125μm) to maintain ≤10^-12 BER.
• Installation & Wiring Safety:
  • Optical Connector Handling: Use lint-free wipes and optical-grade cleaner to clean SC/ST connectors—dust or oil on ferrules causes signal attenuation (≥3dB loss), leading to link failures; avoid touching connector tips with bare hands.
  • Fiber Bending Radius: Maintain minimum bending radius (20mm for 50/125μm fiber; 25mm for 62.5/125μm fiber)—excessive bending (e.g., <10mm) breaks the fiber core, resulting in permanent link loss; use fiber cable trays with smooth bends.
  • Electrical Isolation Verification: Confirm 5kV isolation between electrical and optical segments using a megohmmeter—reduced isolation indicates a damaged transceiver, posing shock risks and compromising noise immunity.
• Operation & Maintenance:
  • Link Loss Testing: Perform annual link loss tests (using an optical power meter) to verify ≤3dB loss—gradual loss (e.g., ≥5dB) indicates aging connectors or fiber damage; replace components before link failure.
  • LED Status Monitoring: Address red link LEDs immediately—common causes include broken fiber, mismatched transceivers, or power loss to the remote rack; use an optical continuity tester to isolate the fault.
  • Hot-Swap Limitations: Do not hot-swap the TB811 while the bus is active—sudden optical signal loss may cause bus reinitialization and temporary I/O disruption; schedule replacement during planned maintenance.
• Environmental Limitations:
  • Condensing Humidity: Avoid operation in condensing humidity (>95% RH, 40℃)—moisture seeps into optical connectors, causing corrosion and signal loss; use hermetic fiber enclosures and desiccants in humid environments (e.g., offshore platforms).
  • Temperature Extremes: Do not operate above +70℃ or below -25℃—high temperatures degrade laser output power, while extreme cold increases fiber brittleness; use heated/cooled cabinets in extreme zones (e.g., desert refineries, arctic pipelines).
• Replacement & Spare Parts:
  • Genuine ABB Components: Use only genuine ABB TB811 (3BSE008568R1) units—non-genuine transceivers have inconsistent optical power output and no S800 compatibility, leading to frequent link failures and potential bus crashes.
  • Spare Inventory: Maintain 1 spare unit per 5 optical bus segments—TB811 failures disconnect entire remote I/O racks; spares reduce downtime from 2+ weeks (delivery) to <1 hour for mission-critical systems (e.g., nuclear plant safety buses)
