ABB TAS01 Turbine Automatic Synchronization Module

Product Model

ABB TAS01 Turbine Automatic Synchronization Module

Product Overview

The ABB TAS01 is an automatic synchronization control module designed for power turbines, enabling generators to synchronize automatically with the electrical grid. The module precisely measures and regulates generator voltage, frequency, and phase to ensure optimal grid connection, minimizing mechanical stress and grid disturbances. TAS01 features fast response and high-precision control, making it an essential component in power plant and large industrial power automation systems.

Technical Specifications (Typical)

• Model: TAS01

• Type: Turbine Automatic Synchronization Module

• Input Signals: Generator voltage, frequency, and phase signals

• Output Signals: Synchronization control commands (excitation or speed adjustment)

• Control Accuracy: Frequency ±0.01 Hz, Voltage ±0.5%, Phase ±0.5°

• Response Time: < 50 ms

• Supply Voltage: 24 V DC / 48 V DC

• Communication Interface: Optional Profibus / Modbus / ABB internal bus

• Operating Temperature: –20°C to +60°C

• Mounting: Control cabinet panel or DIN rail

• Status Indicators: LED for power, synchronization status, and fault

• Protection Rating: IP20 / optional IP54

Features and Advantages

1. High-Precision Synchronization: Accurate control of generator voltage, frequency, and phase ensures smooth grid connection.

2. Fast Response: Low-latency processing reduces mechanical stress and grid disturbance.

3. Intelligent Functionality: Automatically monitors generator status and generates synchronization commands to enhance automation.

4. Modular Design: Compact structure for easy integration into control cabinets with other protection and control modules.

5. Multi-Interface Support: Supports multiple communication protocols for seamless integration with PLCs and supervisory systems.

6. High Reliability: Industrial-grade design with strong EMI resistance, suitable for power plants and large industrial environments.

Application Areas

• Synchronization control for steam, gas, nuclear, and hydro turbines

• Industrial power plant automation systems

• Large grid-connected generator synchronization

• Self-generation power plants in industrial enterprises

• Smart grids and distributed generation control

Precautions



1. Disconnect power before installation to ensure safety.

2. Follow wiring diagrams and module instructions strictly to avoid incorrect connections.

3. Avoid high humidity, high temperature, and corrosive gases in the working environment.

4. Periodically check input/output signals and status indicators to ensure safe and stable operation.

5. Do not operate beyond rated voltage, load, or signal ranges.

6. Module setup, adjustment, and maintenance should be performed by qualified personnel.
