ABB SST-DN3-PCI-2 interface card

Product Model

ABB SST-DN3-PCI-2 Interface Card

Product Overview

The ABB SST-DN3-PCI-2 is a high-performance industrial interface card designed for automation systems and computer control environments. It provides a PCI bus connection for high-speed data exchange between ABB controllers or servo systems and a computer. The SST-DN3-PCI-2 enables real-time control, data acquisition, and communication processing, supporting multi-channel I/O and diagnostic functions, making it ideal for industrial automation, robotics, and process control systems.

Technical Specifications (Typical)

• Model: SST-DN3-PCI-2

• Type: Industrial Interface Card

• Bus Interface: PCI 2.0

• I/O Type: Multi-channel digital and analog interfaces

• Supported Protocols: ABB internal communication protocol / optional Modbus

• Data Transfer Rate: Up to 33 MHz (PCI bus rate)

• Supply Voltage: 5 V / 12 V DC (via PCI bus)

• Operating Temperature: 0°C to +60°C

• Mounting: Standard PCI slot

• Status Indicators: LED for power, data transfer, and fault status

• Protection Rating: Compliant with industrial electronics standards

Features and Advantages

1. High-Speed Data Communication: Supports PCI bus for fast real-time control data exchange.

2. Multi-Channel I/O: Flexible configuration for multiple digital and analog signals.

3. Modular Installation: Standard PCI slot for easy integration into computers or industrial control systems.

4. High Reliability: Industrial-grade design with strong EMI immunity for harsh environments.

5. Status Monitoring: LED indicators for operational and fault status for easy maintenance.

6. Good Compatibility: Seamlessly interfaces with ABB controllers, servo systems, and other industrial equipment.

Application Areas

• Interface between industrial automation systems and computer control

• Data acquisition and communication for PLCs or servo systems

• Robotic control systems

• Automated production line monitoring and control

• Process control systems and laboratory automation

Precautions

1. Power off the computer or control system before installation to avoid damaging the card.

2. Install according to PCI slot specifications and ensure the card is securely seated.

3. Keep the working environment dry and ventilated, avoiding high temperature, humidity, and corrosive gases.

4. Do not exceed the rated PCI bus voltage and load.

5. Periodically check the card and connection cables to ensure reliable communication.

6. Installation and maintenance should be performed by qualified personnel.

---
