ABB SPNPM22 Network Processor Module
Product Description
A core network processor module for ABB Symphony Plus automation systems, dedicated to managing data transmission between distributed I/O modules (e.g., NASI-02, NMFC02) and central controllers. It supports multi-protocol conversion and real-time data routing, acting as a "communication hub" to ensure stable, high-speed data exchange in large-scale industrial control networks.
Key Specifications
- Communication Interfaces: 2×Ethernet ports (100Mbps, TCP/IP); 1×PROFIbus DP port (12Mbps); 1×RS-485 port (Modbus RTU).
- Supported Protocols: ABB Symphony Plus Loop, PROFIbus DP-V1, Modbus RTU, TCP/IP (for DCS integration).
- Data Processing: 32-bit industrial processor; max data throughput 100Mbps; real-time response ≤10ms.
- Redundancy: Supports 1+1 module redundancy and dual-network redundancy (Ethernet/PROFIbus); auto-failover ≤50ms.
- Power Supply: 24V DC (18-30V DC); power consumption ≤6W (full load).
- Environment: Operating temperature -40°C to +70°C; humidity 5%-95% (non-condensing); IP20.
- Mechanical: 35mm DIN rail-mounted; dimensions 110×85×25mm; compatible with ABB Symphony Plus I/O racks.
- Isolation: 2.5kV AC isolation between network ports and system backplane; ESD protection (IEC 61000-4-2, ±8kV).
- Catalog No.: SPNPM22 (compatible part numbers: GJR5254000R0001, regional specs consistent).
Advantages & Features
- Multi-Protocol Integration: Supports Ethernet, PROFIbus DP, and Modbus RTU, enabling seamless communication between ABB native modules and third-party devices (e.g., inverters, HMIs).
- High-Speed & Real-Time Performance: 100Mbps throughput and ≤10ms response meet the real-time demands of industrial control (e.g., chemical batch processes, power plant auxiliary control).
- Dual Redundancy Design: Module and network redundancy avoid communication interruptions caused by hardware failures or network faults, critical for high-reliability scenarios (e.g., oil refining).
- Easy Configuration & Diagnostics: Configurable via ABB Control Builder M; built-in network status monitoring (e.g., packet loss, connection errors) for quick troubleshooting.
- Wide Compatibility: Native integration with ABB Symphony Plus I/O modules; plug-and-play installation reduces commissioning time.
Application Fields
- Large-Scale Power Plants: Connects boiler/turbine auxiliary I/O modules (e.g., NASI-02, NMFC02) to the central DCS, enabling unified monitoring and control of distributed systems.
- Chemical Complexes: Links reactor zone I/O modules and batch control controllers via Ethernet/PROFIbus DP, ensuring real-time data sync for sequential production.
- Oil & Gas Refineries: Uses redundancy to transmit wellhead pressure/flow data to the central control room, avoiding production interruptions from network failures.
- Water Treatment Plants: Integrates distributed dosing system I/O modules and SCADA systems via Modbus RTU, realizing remote monitoring of water treatment processes.
Precautions
- Network Configuration: Set unique IP addresses for Ethernet ports; avoid IP conflicts in the same network. Configure PROFIbus DP baud rate (12Mbps max) to match connected devices.
- Redundancy Setup: When enabling 1+1 redundancy, ensure master/slave modules have identical firmware and configuration; test failover functionality quarterly.
- Wiring: Use shielded cables for PROFIbus DP/RS-485; ground shields at both ends (for PROFIbus) to reduce interference. Use CAT5e or higher cables for Ethernet.
- Power Supply: Use a regulated 24V DC power supply with overload/overvoltage protection; do not power on until wiring is completed.
- Maintenance: Check network status indicators (link, data transmission) daily; update firmware annually via ABB service software. Clean dust from vents every 3-6 months to prevent overheating.
English Translation
ABB SPNPM22 Network Processor Module
Product Description
A core network processor module for ABB Symphony Plus automation systems, dedicated to managing data transmission between distributed I/O modules (e.g., NASI-02, NMFC02) and central controllers. It supports multi-protocol conversion and real-time data routing, acting as a "communication hub" to ensure stable, high-speed data exchange in large-scale industrial control networks.
Key Specifications
- Communication Interfaces: 2×Ethernet ports (100Mbps, TCP/IP); 1×PROFIbus DP port (12Mbps); 1×RS-485 port (Modbus RTU).
- Supported Protocols: ABB Symphony Plus Loop, PROFIbus DP-V1, Modbus RTU, TCP/IP (for DCS integration).
- Data Processing: 32-bit industrial processor; max data throughput 100Mbps; real-time response ≤10ms.
- Redundancy: Supports 1+1 module redundancy and dual-network redundancy (Ethernet/PROFIbus); auto-failover ≤50ms.
- Power Supply: 24V DC (18-30V DC); power consumption ≤6W (full load).
- Environment: Operating temperature -40°C to +70°C; humidity 5%-95% (non-condensing); IP20.
- Mechanical: 35mm DIN rail-mounted; dimensions 110×85×25mm; compatible with ABB Symphony Plus I/O racks.
- Isolation: 2.5kV AC isolation between network ports and system backplane; ESD protection (IEC 61000-4-2, ±8kV).
- Catalog No.: SPNPM22 (compatible part numbers: GJR5254000R0001, regional specs consistent).
Advantages & Features
- Multi-Protocol Integration: Supports Ethernet, PROFIbus DP, and Modbus RTU, enabling seamless communication between ABB native modules and third-party devices (e.g., inverters, HMIs).
- High-Speed & Real-Time Performance: 100Mbps throughput and ≤10ms response meet the real-time demands of industrial control (e.g., chemical batch processes, power plant auxiliary control).
- Dual Redundancy Design: Module and network redundancy avoid communication interruptions caused by hardware failures or network faults, critical for high-reliability scenarios (e.g., oil refining).
- Easy Configuration & Diagnostics: Configurable via ABB Control Builder M; built-in network status monitoring (e.g., packet loss, connection errors) for quick troubleshooting.
- Wide Compatibility: Native integration with ABB Symphony Plus I/O modules; plug-and-play installation reduces commissioning time.
Application Fields
- Large-Scale Power Plants: Connects boiler/turbine auxiliary I/O modules (e.g., NASI-02, NMFC02) to the central DCS, enabling unified monitoring and control of distributed systems.
- Chemical Complexes: Links reactor zone I/O modules and batch control controllers via Ethernet/PROFIbus DP, ensuring real-time data synchronization for sequential production.
- Oil & Gas Refineries: Uses redundancy to transmit wellhead pressure/flow data to the central control room, avoiding production interruptions from network failures.
- Water Treatment Plants: Integrates distributed dosing system I/O modules and SCADA systems via Modbus RTU, realizing remote monitoring of water treatment processes.
Precautions
- Network Configuration: Set unique IP addresses for Ethernet ports; avoid IP conflicts in the same network. Configure PROFIbus DP baud rate (12Mbps max) to match connected devices.
- Redundancy Setup: When enabling 1+1 redundancy, ensure master/slave modules have identical firmware and configuration; test failover functionality quarterly.
- Wiring: Use shielded cables for PROFIbus DP/RS-485; ground shields at both ends (for PROFIbus) to reduce interference. Use CAT5e or higher cables for Ethernet.
- Power Supply: Use a regulated 24V DC power supply with overload/overvoltage protection; do not power on until wiring is completed.
- Maintenance: Check network status indicators (link, data transmission) daily; update firmware annually via ABB service software. Clean dust from vents every 3-6 months to prevent overheating.
-
-
