ABB SPAD346C Stable Differential Relay
Item NO.:
SPAD346CPayment:
T/TPrice:
$1200Product Origin:
ChinaColor:
NEWLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The ABB SPAD346C is a stabilized differential relay designed for transformer and generator-transformer differential protection. Its stabilized design ensures reliability under inrush currents, CT saturation, and transient system conditions, preventing false tripping. The relay integrates three-phase differential protection, overcurrent protection, and earth-fault protection, providing high-reliability protection for large power equipment.
| Parameter | Specification |
|---|---|
| Model | SPAD346C |
| Rated Input Current | 1 A or 5 A (secondary) |
| Supply Voltage Range | AC/DC 80–265 V or DC 18–80 V (module-dependent) |
| Operating Time | Instantaneous differential stage approx. 30–40 ms |
| Modules | Differential module (SPCD 3D53), Earth-fault module (SPCD 2D55), Overcurrent/Earth-fault combination module (SPCJ 4D28) |
| Special Features | Second harmonic restraint (inrush protection), Fifth harmonic restraint (overexcitation protection), Digital CT ratio correction, Vector group compensation |
| Environmental Adaptation | High electromagnetic interference immunity, suitable for industrial power environments |
| Outputs | Multiple heavy-duty relay outputs, programmable I/O, disturbance recording |
Advantages
High sensitivity and stability: Accurate operation during inrush or CT saturation.
Integrated multi-function: Combines differential, overcurrent, and earth-fault protection.
Broad compatibility: Supports various transformer winding structures, CT ratios, and connection schemes.
Features
Digitally adjustable differential starting ratio and basic settings for load-based sensitivity calibration.
Built-in second and fifth harmonic restraint for inrush and overexcitation.
Event and disturbance recording for post-fault analysis.
Rugged design for high-voltage, high-current industrial environments.
User interface displays phase angle and current for verification of measurement circuits and vector group matching.
Two-winding power transformer protection (winding short-circuit, inter-turn faults, earth faults).
Generator-transformer unit protection.
Three-winding transformer protection (under specified short-circuit conditions).
Power systems, substations, and large industrial plants requiring comprehensive differential, earth-fault, and overcurrent protection.
Verify transformer connection, vector group, and CT ratio compatibility before selection.
Ensure proper CT polarity, correct wiring, and secure module installation before powering.
Digitally configure differential starting ratio, basic settings, and second knee point to balance sensitivity and stability.
Avoid installation in high temperature, high humidity, vibration, or strong electromagnetic interference areas.
Periodically check harmonic restraint functionality and event recording to ensure proper operation.
Maintain parameter settings, firmware version, and event logs for maintenance and replacement purposes.
The structure and details of the product：
Please make an inquiry for more models
