ABB SNAT-7780-CNT analog input module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB SNAT-7780-CNT is an industrial analog input module designed for signal acquisition and processing in motor drive systems, PLC/DCS control systems, and industrial automation equipment. The module accurately acquires voltage and current analog signals and converts them into digital signals for higher-level control systems. SNAT-7780-CNT is compact, fast-responding, and reliable, widely used for monitoring and feedback in industrial control systems.

2. Technical Specifications

• Model: SNAT-7780-CNT

• Type: Analog Input Module

• Input Type: Voltage, current analog signals

• Input Channels: 8–16 channels (depending on version)

• Input Range:

  • Voltage: 0–10 V / ±10 V

  • Current: 0–20 mA / 4–20 mA

• Resolution: 16-bit ADC

• Sampling Rate: Up to 1 kHz per channel

• Supply Voltage: 24 V DC (typical)

• Power Consumption: < 5 W

• Operating Temperature: -20°C to +60°C

• Storage Temperature: -40°C to +85°C

• Humidity Range: 5% – 95% (non-condensing)

• Interface: Digital bus interface (CAN / RS485 / Ethernet, optional)

• Status Indicators: LEDs for module status and fault

• Mounting: DIN rail or panel mount

• Standards: CE / IEC 61800 / UL industrial standards

3. Advantages & Features

1. High-precision signal acquisition

   • 16-bit ADC ensures accurate analog-to-digital conversion of signals.

2. Multi-channel support

   • Simultaneously acquires 8–16 analog signals for complex control systems.

3. High-speed response

   • Fast sampling rate meets real-time control and monitoring requirements.

4. Industrial-grade reliability

   • Anti-interference design suitable for high temperature, high humidity, and harsh environments.

5. Compact modular design

   • Saves cabinet space and integrates easily with other modules.

6. Clear status monitoring

   • LED indicators for operation and fault status facilitate maintenance and troubleshooting.

4. Application Areas

• Industrial motor drive systems

• PLC / DCS analog signal acquisition

• Production line automation and process control systems

• Fans, pumps, conveyor systems, and elevator control

• Heavy machinery monitoring and control

• Factory automation and Industrial IoT (IIoT) systems

5. Precautions & Recommendations

1. Voltage and current matching

   • Input signals must comply with module specifications to avoid overvoltage or overcurrent damage.

2. Proper wiring

   • Connect analog inputs according to the manual for accurate signal acquisition.

3. Environmental conditions

   • Install in dry, ventilated, non-corrosive environments with proper heat dissipation.

4. ESD protection

   • Observe anti-static precautions during installation and maintenance.

5. Regular inspection

   • Check LED status, terminal connections, and module operation for long-term stable performance.

6. Safe operation

   • Disconnect power before operating or maintaining the module to prevent electric shock or equipment damage.
