ABB SNAT-7261 main interface board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB SNAT-7261 is an industrial main interface board designed for core signal processing and interface management in motor drive systems, PLC/DCS control systems, and industrial automation equipment. It integrates multiple input/output interfaces, supports analog, digital, and communication signals, enabling efficient data exchange between motor control systems and higher-level control systems. SNAT-7261 is reliable, fast-responding, and a key component in high-performance industrial control systems.

2. Technical Specifications

• Model: SNAT-7261

• Type: Main Interface Board

• Applicable Systems: Motor drive systems, PLC/DCS control systems

• Input Interfaces:

  • Digital inputs (DI)

  • Analog inputs (AI)

  • Communication interfaces (CAN, RS485, Ethernet, optional)

• Output Interfaces:

  • Digital outputs (DO)

  • Analog outputs (AO)

• Control Signals: PWM, digital switching signals, analog voltage/current

• Supply Voltage: 24 V DC (typical)

• Power Consumption: < 10 W

• Operating Temperature: -20°C to +60°C

• Storage Temperature: -40°C to +85°C

• Humidity Range: 5% – 95% (non-condensing)

• Mounting: DIN rail or panel mount

• Status Indicators: LEDs for power, communication, and fault

• Standards: CE / IEC 61800 / UL industrial standards

3. Advantages & Features

1. High-performance signal processing

   • Accurately processes analog, digital, and communication signals for fast and reliable system response.

2. Multi-interface support

   • Supports various I/O interfaces and industrial communication protocols for seamless integration with PLCs, DCS, and inverters.

3. High reliability

   • Industrial-grade design with strong interference immunity for complex environments.

4. Compact modular design

   • Saves cabinet space and can be combined with other control modules.

5. Clear status monitoring

   • LED indicators show power, communication, and fault status for quick diagnostics and maintenance.

6. Easy installation and maintenance

   • DIN rail or panel mounting with modular design for easy replacement and upgrades.

4. Application Areas

• Industrial motor drive systems

• PLC / DCS control system interface management

• Production line automation and robotic control

• Fans, pumps, elevators, and conveyor control

• Heavy machinery signal integration and control

• Factory automation and process control systems

5. Precautions & Recommendations

1. Voltage matching

   • Ensure 24 V DC supply to avoid circuit damage.

2. Proper wiring

   • Connect digital, analog, and communication interfaces according to the manual to ensure stable signal transmission.

3. Environmental conditions

   • Install in a dry, ventilated, non-corrosive environment with adequate heat dissipation.

4. ESD protection

   • Observe anti-static precautions during installation and maintenance.

5. Regular inspection

   • Check LED status, terminal tightness, and module operation for stable system performance.

6. Safe operation

   • Disconnect power before installation or maintenance to prevent electric shock or equipment damage.
