ABB SM1006S/B20/0000/22/STD

Product Description

The ABB SM1006S/B20/0000/22/STD is a dedicated signal processing module designed for industrial automation systems (e.g., ABB AC 800M, Symphony Plus). It specializes in conditioning and converting analog/digital signals from field sensors (e.g., temperature, pressure transmitters) into standardized data for upper-level controllers. It integrates signal filtering, isolation, and linearization functions, ensuring stable and accurate signal transmission in harsh industrial environments—ideal for medium-complexity process control scenarios.

Key Specifications
- Signal Input: 6 analog input channels (4-20mA/0-10V configurable per channel); input impedance: 250Ω (4-20mA), 1MΩ (0-10V).
- Signal Output: 2 analog output channels (4-20mA); accuracy ±0.1% full scale (FS).
- Signal Processing: Built-in low-pass filter (50Hz/60Hz cutoff); linearization error ≤0.05% FS; amplification gain 1-5x adjustable.
- Communication: 1 PROFIbus DP port (12Mbps max) for data sync with controllers.
- Power Supply: 24V DC (18-30V DC); power consumption ≤4W (full load).
- Environmental Adaptability: Operating temperature -40°C to +70°C; humidity 5%-95% (non-condensing); IP20.
- Mechanical: 35mm DIN rail-mounted; dimensions 100×80×25mm; compatible with ABB standard I/O racks.
- Protection: 2.5kV AC galvanic isolation (input/output/ power); ESD protection (IEC 61000-4-2, ±8kV contact).
- Certifications: CE, UL; compliant with IEC 61131-2 industrial standards.
Advantages & Features
1. Multi-Channel Flexibility: 6 analog inputs + 2 analog outputs meet multi-point signal processing needs; per-channel input type configuration adapts to diverse sensors (e.g., 4-20mA pressure transmitters, 0-10V level sensors).
1. High-Precision Transmission: ±0.1% FS output accuracy and low-pass filtering eliminate signal distortion from long-distance wiring or electrical interference, ensuring reliable controller data.
1. Strong Isolation Protection: 2.5kV AC isolation blocks ground loops and field electrical noise (e.g., from motors, inverters), stable in high-interference environments.
1. Easy Integration: PROFIbus DP port enables seamless connection to ABB controllers; configurable via ABB Control Builder M software, no custom hardware adapters needed.
1. Compact Space-Saving: 100×80×25mm small form factor saves control cabinet space, suitable for dense module installation scenarios.
Application Fields
1. Process Industry: Conditions 4-20mA temperature/pressure signals from chemical reactor transmitters, converting to standardized data for DCS process monitoring.
1. Power Plants: Processes 0-10V steam flow signals in turbine auxiliary systems, filtering noise from high-voltage equipment for stable flow control.
1. Water Treatment: Adjusts 4-20mA turbidity/PH signals from water quality sensors, providing accurate data for dosing system regulation.
1. Manufacturing: Amplifies weak 4-20mA vibration signals from industrial machine sensors, enabling early fault detection of production equipment.
Precautions
1. Wiring: Use shielded twisted-pair cables (0.5-1.0mm²) for input/output wiring; ground shield at module end (single-point) to reduce EMI.
1. Signal Matching: Confirm input signal type (4-20mA/0-10V) per channel before wiring; avoid input overrange (>30V for voltage, >30mA for current) to prevent module damage.
1. Power Supply: Use a regulated 24V DC power supply with overload protection; check polarity before power-on—reverse connection may damage internal components.
1. Installation Environment: Avoid direct sunlight, corrosive gas, or high humidity (>95% non-condensing); keep 5cm clearance around the module for heat dissipation.
1. Maintenance: Calibrate channels quarterly with ABB tools; clean dust from vents every 3-6 months. If output signal drifts significantly, check isolation circuits or replace the module.
