ABB SH201L (Order Code: 2CDS241001R0164) Miniature Circuit Breaker

1. Key Parameters

• Product Model: SH201L
• Order Code/Part Number: 2CDS241001R0164 (unique identifier for procurement and compatibility verification)
• Product Series: ABB SH200 series (miniature circuit breakers for low-voltage distribution)
• Core Function: Protects low-voltage circuits from overcurrent and short-circuit faults; enables manual circuit isolation for maintenance
• Electrical Specifications:
  • Rated Voltage (Ue): 230/400V AC (single-phase/three-phase compatible)
  • Rated Current (In): 6A (fixed; optimized for low-power circuits like lighting or small appliances)
  • Tripping Curve: C-curve (trips at 5×In~10×In; ideal for resistive/capacitive loads: lighting, HVAC, household appliances)
  • Breaking Capacity (Icu): 6kA (at 230/400V AC; safely interrupts short-circuit currents up to 6kA)
  • Rated Frequency: 50/60Hz (universal for global power grids)
  • Insulation Voltage (Ui): 690V AC (ensures electrical isolation between live parts and enclosure)
  • Dielectric Strength: 2.5kVrms (1-minute test between live parts and ground)
• Mechanical Specifications:
  • Pole Configuration: 1-pole (protects single live conductor; neutral wire requires separate protection if needed)
  • Mounting: DIN rail-mounted (compatible with 35mm standard DIN rails per EN 60715)
  • Dimensions (W×H×D): 18mm × 89mm × 74mm (slim 18mm width; saves space in distribution boards)
  • Operating Mechanism: Toggle switch (ON/OFF position; tripped state indicated by middle position)
  • Reset Method: Manual (toggle switch must be reset to OFF before switching ON after tripping)
  • Weight: Approximately 80g
• Environmental Ratings:
  • Operating Temperature Range: -25℃~+60℃ (-13℉~140℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: ≤95% RH (non-condensing, 40℃)
  • Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6; no unintended tripping)
  • Shock Resistance: 30g acceleration (11ms duration, IEC 60068-2-27; maintains structural integrity)
• Compliance Standards: IEC 60898-1 (miniature circuit breakers for household and similar use), EN 60898-1, UL 489 (North American safety standard), CE, RoHS

Note: The "L" suffix in "SH201L" indicates compliance with enhanced breaking capacity or regional safety requirements (varies by market; confirm with local ABB documentation for region-specific details).

2. Key Features

• Precise Overcurrent & Short-Circuit Protection: C-curve tripping characteristic (5×In~10×In) balances sensitivity and robustness—avoids nuisance tripping from temporary load surges (e.g., HVAC startup) while rapidly interrupting short-circuit currents (≤0.1s at 10×In) to prevent equipment damage or fire.
• Space-Saving DIN Rail Design: 18mm slim width allows dense installation in distribution boards (e.g., residential consumer units, commercial panelboards)—critical for applications with limited space.
• Universal Voltage/Frequency Compatibility: 230/400V AC and 50/60Hz operation ensures global usability, eliminating the need for region-specific models in multi-market projects.
• Intuitive Status Indication: Toggle switch position clearly signals circuit status:
  • ON: Switch aligned with "I" mark (circuit energized).
  • OFF: Switch aligned with "O" mark (circuit isolated).
  • Tripped: Switch in middle position (fault detected; power interrupted).
• Robust Construction: Flame-retardant thermoplastic housing (UL94 V-0) resists ignition and high temperatures—complies with fire safety standards for enclosed electrical equipment. Copper alloy current-carrying parts ensure low resistance and long-term reliability.
• Easy Installation & Maintenance: Tool-less DIN rail mounting and push-in wire terminals (accepts 1.5mm²~4mm² copper conductors) simplify installation. Manual reset and clear tripping indication reduce troubleshooting time during faults.
• RoHS Compliance: Free of hazardous substances (lead, mercury, cadmium) to meet global environmental regulations—suitable for eco-sensitive applications like green buildings or medical facilities.

3. Application Fields

• Residential Electrical Systems: Installed in consumer units (breaker boxes) to protect individual circuits:
  • Lighting circuits (LED, incandescent, or fluorescent fixtures).
  • Small appliance circuits (refrigerators, microwaves, televisions).
  • Low-power HVAC circuits (window air conditioners, small heaters).
• Commercial Buildings: Used in panelboards for offices, retail stores, and hotels to protect:
  • Office equipment circuits (computers, printers, copiers).
  • Lighting systems (recessed lights, signage, emergency lighting).
  • Retail display circuits (LED screens, product showcases).
• Light Industrial Applications: Deployed in control panels for small-scale manufacturing or workshops to protect:
  • Low-power motor circuits (small pumps, fans, conveyors).
  • Instrumentation circuits (sensors, meters, small control devices).
  • Bench tool circuits (drills, grinders, soldering stations).
• Medical Facilities (Non-Critical Areas): Used in non-patient-care zones (offices, storage rooms) to protect standard electrical loads—complies with safety standards for low-risk medical environments.
• Data Centers (Auxiliary Circuits): Protects auxiliary systems (lighting, office areas, cooling fans) in data centers—complementary to high-grade protection for critical IT infrastructure.
• Renewable Energy Systems (Small-Scale): Integrated into residential solar inverters or small wind turbine systems to protect low-voltage DC/AC conversion circuits—ensuring safe operation of distributed energy resources.

4. Precautions

• Current Rating Matching: Ensure the MCB’s rated current (6A) matches the maximum load of the protected circuit. Overloading (e.g., connecting a 10A appliance to a 6A circuit) causes frequent tripping or permanent MCB damage.
• Pole Configuration & Neutral Protection: The 1-pole design protects only the live conductor. For circuits requiring neutral protection (e.g., sensitive electronics), pair with a separate neutral MCB or use a 2-pole model (e.g., SH202L).
• Tripping Curve Compatibility: C-curve is designed for resistive/capacitive loads. For inductive loads (e.g., large motors) that cause high inrush currents, use a D-curve MCB (e.g., SH201D) to avoid nuisance tripping.
• Wiring Safety:
  • Use copper conductors (1.5mm²~4mm²) and tighten push-in terminals to the specified torque (0.8~1.2N·m) to prevent loose connections (which cause overheating).
  • Do not exceed the maximum wire length for the circuit (calculate based on voltage drop; ≤5% for 230V AC circuits).
• Installation Environment:
  • Install in enclosed distribution boards to protect from dust, moisture, and direct sunlight. Avoid temperatures outside -25℃~+60℃ or humidity >95% RH (non-condensing).
  • In corrosive environments (e.g., coastal areas), use anti-corrosion coatings or select stainless steel accessories for the distribution board.
• Fault Handling:
  • After tripping, identify the fault cause (overload/short circuit) before resetting. Do not force the toggle switch—this may damage the tripping mechanism.
  • If the MCB trips immediately after reset, check for short circuits (e.g., damaged wires, faulty appliances) and repair before re-energizing.
• Maintenance & Replacement:
  • Inspect annually for signs of damage (cracks, discoloration, loose terminals). Replace if any damage is found—damaged MCBs may fail to trip during faults, risking fire.
  • Do not modify the MCB (e.g., adjusting tripping settings) or use it for unapproved applications (e.g., DC circuits beyond 250V DC)—this voids safety certifications and creates hazards
