ABB SGHF-1001 terminal module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB SGHF-1001 is an industrial terminal module designed for centralized wiring of signals, control, and power in electrical control systems. It provides reliable terminal connections and distribution interfaces for automation equipment, inverters, PLC systems, and control cabinets. SGHF-1001 features compact design, easy installation, clear wiring, and simple maintenance, making it an essential component in industrial control systems.

2. Technical Specifications

• Model: SGHF-1001

• Type: Terminal Module

• Rated Voltage: 600 V AC/DC

• Rated Current: 10 A

• Connection Type: Screw / Spring terminals (depending on variant)

• Wire Cross-section: 0.5 – 2.5 mm²

• Number of Poles: Standard 1 pole, can be combined for multiple poles

• Insulation Material: High-strength flame-retardant plastic

• Operating Temperature: -25°C to +70°C

• Storage Temperature: -40°C to +85°C

• Protection Class: IP20

• Mounting: DIN rail mount

• Labeling: Supports label markers for easy identification

• Standards: IEC 60947-7-1 / UL 1059

3. Advantages & Features

1. High reliability

   • Industrial-grade materials and design ensure long-term stable operation.

2. Easy installation

   • DIN rail mount and modular design allow quick installation and flexible pole combination.

3. Clear wiring

   • Screw or spring terminals secure wires firmly, reducing risk of loose connections.

4. Simple maintenance

   • Removable modular design allows easy maintenance and wiring adjustments.

5. Label management

   • Supports labeling for clear wire identification and efficient operation.

6. Standards compliant

   • Compatible with ABB and other industrial control products.

4. Application Areas

• Industrial automation control systems

• PLC / DCS wiring

• Inverter and drive control cabinets

• Power distribution and control cabinets

• Centralized wiring for machinery

• Factory automation and process control systems

5. Precautions & Recommendations

1. Voltage and current matching

   • Ensure rated voltage and current of the module meet actual load requirements.

2. Wiring standards

   • Use correct wire cross-section and tightening method according to manual to prevent loose connections or short circuits.

3. Environmental conditions

   • Install in a dry, ventilated, and non-corrosive environment.

4. Regular inspection

   • Periodically check terminal tightness and insulation for reliable connections.

5. ESD protection

   • Observe anti-static precautions during installation and maintenance.

6. Safe operation

   • Disconnect power before wiring or maintenance to prevent electric shock.
