ABB SDCS-PIN-4 Pulse Transformer Board

ABB SDCS-PIN-4 Pulse Transformer Board

ABB SDCS-PIN-4 Pulse Transformer Board

  • Item NO.:

    SDCS-PIN-4
  • Payment:

    T/T
  • Price:

    $545
  • Product Origin:

    Germany
  • Color:

    NEW
  • Goods stock:

    2
  • Product weight:

    1.18KG
  • Lead Time:

    in stock

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us

      1.

        ABB SDCS-PIN-4 Pulse Transformer / Power Interface Board

        Overview

        Core power interface board exclusively for ABB DCS800 series thyristor DC drives, connecting main control board SDCS-CON-4 and power thyristor power unit. It integrates pulse transformer drive circuit, auxiliary power supply, voltage/current sampling and hardware protection circuits, the key signal conversion medium between control logic and power stageeero.
        SDCS-PIN-4 Board


        Core Specifications

        • Auxiliary power input: 115/230V AC auto-adaptation
        • Multi-channel isolated DC power output for drive control circuit
        • Built-in pulse transformers to isolate and amplify thyristor trigger pulses
        • Sampling interfaces: armature current CT, DC bus voltage, heatsink PTC temperature
        • On-board snubber protection circuit for thyristor bridge
        • Internal fuses for field winding and measurement circuit overcurrent protection
        • Equipped with relay DO8 for configurable fault/alarm output
        • Operating temperature: -20℃ ~ +60℃; coated version SDCS-PIN-4-COAT for corrosive environments
        • Connected to SDCS-CON-4 via flat cable inside DCS800 D1-D4 frame

        Key Features

        1. Pulse transformer galvanic isolation separates low-voltage control and high-power main circuit, anti-surge interference
        2. Real-time sampling of current, voltage and temperature signals for drive closed-loop regulation and fault protection
        3. Integrated multi-channel auxiliary power supply for whole drive control system
        4. Thyristor snubber circuit suppresses voltage spikes to protect power semiconductors
        5. Hardware overcurrent, overvoltage and overheat protection to avoid DC drive burnout
        6. Original spare replacement part for 2-quadrant / 4-quadrant DCS800 DC converters

        Applications

        Spare core board for ABB DCS800 DC drives, widely used in metallurgical rolling mills, paper machines, mine hoists, extruders and high-precision winding DC speed regulation equipment.


The structure and details of the product:
