ABB SDCS-PIN-20XB Industrial Automation Drive Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 1. Product Overview

The ABB SDCS-PIN-20XB Drive Board is a core drive control module used in industrial automation systems and robots. It controls servo or stepper motors, integrating a high-speed digital processor, power amplifier, and multiple protection functions. The board enables precise position, speed, and torque control, suitable for high-dynamic and high-precision industrial applications. SDCS-PIN-20XB is compatible with ABB industrial automation systems and supports modular expansion and field wiring.

2. Main Technical Parameters (Typical)

Electrical Data

• Model: SDCS-PIN-20XB

• Input voltage: 24–48 V DC (typical)

• Output current: Max 20 A (peak may be higher depending on motor)

• Power: Typical 400–800 W

• Control mode: Closed-loop servo/stepper control

• Communication interfaces: Industrial bus (CAN, EtherCAT, or ABB dedicated bus)

• Supported feedback: Incremental or absolute encoder

• Protection features: Overcurrent, overvoltage, short-circuit, overtemperature, undervoltage

• Response time: <1 ms

Mechanical & Installation

• Mounting: DIN rail or panel-mounted

• Dimensions: Compact modular design

• Weight: approx. 1–1.5 kg

• Cooling: Natural or forced air

Environmental & Operating Conditions

• Operating temperature: 0°C to +50°C

• Storage temperature: ‑20°C to +70°C

• Relative humidity: 5%–95% (non-condensing)

• EMI/RFI resistance: Industrial-grade interference protection

Standards & Certifications

• Compliant with IEC/EN 61800-5-1/2

• CE, UL, RoHS certified

3. Advantages and Features

• High-precision control: Position, speed, and torque closed-loop control

• Fast response: <1 ms for high-dynamic industrial applications

• Multiple protection features: Protects the board and motor from faults

• Modular design: Easy installation, maintenance, and system expansion

• Strong compatibility: Seamless integration with ABB automation systems and robot controllers

• Industrial reliability: Vibration-resistant, dust-proof, and EMI-resistant design

4. Typical Applications

• Servo/stepper control for ABB industrial robots

• Servo drive systems in automated production lines

• CNC and precision machinery control

• Automated assembly and material handling equipment

• Industrial process control and servo applications

5. Application Notes

• Ensure drive board voltage and current match motor specifications

• Power supply should be stable and sufficient

• Install in a ventilated area and avoid dust accumulation

• Avoid long-term overload operation

• Regularly check terminals, cooling, and communication interfaces

• Confirm communication protocol compatibility with system controller

The structure and details of the product：
