ABB SDCS-CON-H01 Power Interface Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us

1. Product Overview

The ABB SDCS-CON-H01 is a core control and power interface board used in ABB DCS series DC drive systems. It performs internal drive control processing, power interface management, and signal acquisition/output functions. This board is a key component ensuring stable and precise operation of industrial DC drive systems.
It is designed according to industrial-grade standards and provides high reliability in demanding environments.

2. Technical Specifications

• Model: SDCS-CON-H01

• Type: Drive Control & Power Interface Board

• Compatible Systems: ABB DCS Series DC Drives

• Power Supply: Supplied from internal drive power system (typically 24V DC)

• Control Functions:

  • Drive logic control

  • System monitoring

  • Signal conditioning and processing

• Digital I/O: Used for start/stop control and status feedback

• Analog Inputs: Speed reference and current reference signals

• Analog Outputs: Drive status and feedback signals

• Feedback Interface: Supports motor speed feedback (depending on configuration)

• Communication Interfaces:

  • ABB DDCS fiber optic communication (high-speed internal link)

  • Operator panel interface

  • Expansion interface for additional I/O or fieldbus modules

• Mounting Method: Plug-in installation inside drive control cabinet

• Operating Temperature: Approx. –5°C to +55°C

• Storage Temperature: Approx. –40°C to +70°C

• Environmental Requirements: For installation inside protected electrical cabinets

• EMC Performance: Designed for industrial electromagnetic environments

Note: Exact I/O quantity and interface configuration depend on the specific drive type and installed options.

3. Features & Advantages

1. Integrated Core Control Functions
Combines drive control, signal processing, and power interface management in one module.

2. High-Speed Noise-Immune Communication
Uses ABB DDCS fiber optic communication for strong resistance to electromagnetic interference.

3. Industrial-Grade Reliability
Suitable for harsh industrial environments with high temperature and electrical noise.

4. Modular Expandability
Supports additional communication and function boards for flexible system configuration.

5. Easy Maintenance
Plug-in structure allows quick replacement and reduced downtime.

4. Typical Applications

• DC drive systems in metal rolling mills

• Crane and hoisting equipment

• Paper and printing machinery

• Cable, rubber, and plastic production lines

• Heavy-duty conveyor and processing equipment

• High-power DC motor speed control applications

5. Installation & Safety Notes

1. Do not operate under power
   Always disconnect power before installation or replacement.

2. Use anti-static protection
   Prevent electrostatic discharge damage during handling.

3. Install in proper environment
   Mount inside a clean, ventilated, non-corrosive electrical cabinet.

4. Ensure proper grounding
   Reliable grounding is essential for system stability and noise reduction.

5. Verify parameters after replacement
   Check and confirm drive parameter settings after installing a new board.
